857-023 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 46POS 0.156
| Part | Material - Insulation | Operating Temperature [Max] | Operating Temperature [Min] | Read Out | Termination Rows | Contact Type | Termination | Number of Positions | Gender | Number of Positions/Bay/Row | Contact Finish | Contact Finish Thickness | Contact Finish Thickness | Contact Material | Pitch | Pitch | Card Thickness [Max] | Card Thickness [Min] | Color | Mounting Type | Number of Rows [custom] | Card Type | Flange Feature | Number of Rows | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | Dual | 1 | Semi Bellows | Wire Wrap | 46 | Female | 23 | Gold | 0.25 Ám | 10 Áin | Copper Alloy | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | Through Hole | 2 | Non Specified - Dual Edge | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | Single | 1 | Semi Bellows | Solder | 23 | Female | 23 | Gold | 0.25 Ám | 10 Áin | Copper Alloy | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | Through Hole | Non Specified - Single Edge | Flush Mount M3 Threaded Insert Top Opening | 1 | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | Dual | 1 | Semi Bellows | Wire Wrap | 46 | Female | 23 | Tin | Copper Alloy | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | Through Hole | 2 | Non Specified - Dual Edge | ||||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | Dual | 1 | Semi Bellows | Solder | 46 | Female | 23 | Tin | Copper Alloy | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | Right Angle Through Hole | 2 | Non Specified - Dual Edge | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | Dual | 1 | Semi Bellows | Solder | 46 | Female | 23 | Gold | 0.25 Ám | 10 Áin | Copper Alloy | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | Right Angle Through Hole | 2 | Non Specified - Dual Edge | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | Dual | 1 | Semi Bellows | Solder | 46 | Female | 23 | Tin | Copper Alloy | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | Right Angle Through Hole | 2 | Non Specified - Dual Edge | Flush Mount M3 Threaded Insert Top Opening | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | Single | 1 | Semi Bellows | Solder | 23 | Female | 23 | Tin | Copper Alloy | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | Through Hole | Non Specified - Single Edge | 1 | ||||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | Single | 1 | Semi Bellows | Solder | 23 | Female | 23 | Tin | Copper Alloy | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | Through Hole | Non Specified - Single Edge | 1 | ||||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | Single | 1 | Semi Bellows | Solder | 23 | Female | 23 | Tin | Copper Alloy | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | Right Angle Through Hole | Non Specified - Single Edge | Flush Mount Top Opening Unthreaded | 1 | 0.156 " | 3.96 mm | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | Single | 1 | Semi Bellows | Solder | 23 | Female | 23 | Gold | 0.25 Ám | 10 Áin | Copper Alloy | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | Right Angle Through Hole | Non Specified - Single Edge | Flush Mount Top Opening Unthreaded | 1 | 0.156 " | 3.96 mm |
