4.5 x 4.5 mm Tact Switch for SMT
Description
AI
The PTS647 series is a small 4.5 x 4.5 form factor in SMT version with 3 different heights and 3 available actuation forces, ideal for general usage applications
Beta
⌘K
4.5 x 4.5 mm Tact Switch for SMT
4.5 x 4.5 mm Tact Switch for SMT
| Part | Mounting Type | Circuit | Actuator Orientation | Actuator Type | Actuator Height off PCB, Vertical | Contact Rating @ Voltage | Outline [x] | Outline [y] | Illumination | Ingress Protection | Switch Function | Operating Force | Termination Style | Operating Temperature [Min] | Operating Temperature [Max] | Actuator Height off PCB, Vertical [z] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 LITTELFUSE | Surface Mount | SPST-NO | Top Actuated | Standard | 3.8 mm | 0.05 A 12 VDC | 4.5 mm | 4.5 mm | Non-Illuminated | IP40 | Off-Mom | 0.25 kgf | Gull Wing | -20 ░C | 70 °C | |
 LITTELFUSE | Surface Mount | SPST-NO | Top Actuated | Standard | 0.05 A 12 VDC | 4.5 mm | 4.5 mm | Non-Illuminated | IP40 | Off-Mom | 180 gf | Gull Wing | -40 C | 85 °C | 5 mm | |
 LITTELFUSE | Surface Mount | SPST-NO | Top Actuated | Standard | 0.05 A 12 VDC | 4.5 mm | 4.5 mm | Non-Illuminated | IP40 | Off-Mom | 180 gf | Gull Wing | -40 C | 85 °C | 5 mm | |
 LITTELFUSE | Surface Mount | SPST-NO | Top Actuated | Standard | 0.05 A 12 VDC | 4.5 mm | 4.5 mm | Non-Illuminated | IP40 | Off-Mom | 0.25 kgf | Gull Wing | -20 ░C | 70 °C | 5 mm | |
 LITTELFUSE | Surface Mount | SPST-NO | Top Actuated | Standard | 0.05 A 12 VDC | 4.5 mm | 4.5 mm | Non-Illuminated | IP40 | Off-Mom | 100 gf | Gull Wing | -40 C | 85 °C | 7 mm | |
LITTELFUSE | Surface Mount | SPST-NO | Top Actuated | Standard | 3.8 mm | 0.05 A 12 VDC | 4.5 mm | 4.5 mm | Non-Illuminated | IP40 | Off-Mom | 180 gf | Gull Wing | -40 C | 85 °C | |
LITTELFUSE | Surface Mount | SPST-NO | Top Actuated | Standard | 0.05 A 12 VDC | 4.5 mm | 4.5 mm | Non-Illuminated | IP40 | Off-Mom | 0.25 kgf | Gull Wing | -20 ░C | 70 °C | 7 mm | |
 LITTELFUSE | Surface Mount | SPST-NO | Top Actuated | Standard | 0.05 A 12 VDC | 4.5 mm | 4.5 mm | Non-Illuminated | IP40 | Off-Mom | 100 gf | Gull Wing | -40 C | 85 °C | 7 mm | |
 LITTELFUSE | Surface Mount | SPST-NO | Top Actuated | Standard | 0.05 A 12 VDC | 4.5 mm | 4.5 mm | Non-Illuminated | IP40 | Off-Mom | 100 gf | Gull Wing | -40 C | 85 °C | 5 mm | |
LITTELFUSE | Surface Mount | SPST-NO | Top Actuated | Standard | 0.05 A 12 VDC | 4.5 mm | 4.5 mm | Non-Illuminated | IP40 | Off-Mom | 180 gf | Gull Wing | -40 C | 85 °C | 7 mm |
