307-036 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 36POS 0.156
| Part | Material - Insulation | Termination Rows [custom] | Pitch | Pitch | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Features | Contact Finish | Mounting Type | Read Out | Contact Finish Thickness | Contact Finish Thickness | Number of Positions | Card Thickness [Max] | Card Thickness [Min] | Number of Rows [custom] | Contact Type | Gender | Number of Positions/Bay/Row [custom] | Contact Material | Card Type | Color | Termination | Operating Temperature [Min] | Operating Temperature [Max] | Termination Rows | Number of Positions/Bay/Row | Number of Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 2 | 3.96 mm | 0.156 in | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | Card Extender | Gold | Board Edge Straddle Mount | Dual | 0.25 Ám | 10 Áin | 36 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Semi Bellows | Female | 18 | Copper Alloy | Non Specified - Dual Edge | Green | Solder Eyelet(s) | -40 C | 105 ░C | |||
 EDAC Inc. | Polyester Thermoplastic | 3.96 mm | 0.156 in | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | Gold | Surface Mount | Dual | 0.25 Ám | 10 Áin | 72 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Semi Bellows | Female | Copper Alloy | Non Specified - Dual Edge | Green | Solder Eyelet(s) | -40 C | 105 ░C | 1 | 36 | ||||
 EDAC Inc. | Polyester Thermoplastic | 3.96 mm | 0.156 in | 4-40 Flush Mount Threaded Insert Top Opening | Tin | Surface Mount | Dual | 72 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Semi Bellows | Female | Copper Alloy | Non Specified - Dual Edge | Green | Solder Eyelet(s) | -40 C | 105 ░C | 1 | 36 | ||||||||
 EDAC Inc. | Polyester Thermoplastic | 3.96 mm | 0.156 in | 4-40 Flush Mount Threaded Insert Top Opening | Gold | Through Hole | Single | 0.25 Ám | 10 Áin | 36 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Semi Bellows | Female | Copper Alloy | Non Specified - Single Edge | Green | Solder Eyelet(s) | -40 C | 105 ░C | 1 | 36 | 1 | ||||||
 EDAC Inc. | Polyester Thermoplastic | 2 | 3.96 mm | 0.156 in | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | Tin | Through Hole | Dual | 36 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Semi Bellows | Female | 18 | Copper Alloy | Non Specified - Dual Edge | Green | Wire Wrap | -40 C | 105 ░C | ||||||
 EDAC Inc. | Polyester Thermoplastic | 2 | 3.96 mm | 0.156 in | Gold | Through Hole | Dual | 0.25 Ám | 10 Áin | 36 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Semi Bellows | Female | 18 | Copper Alloy | Non Specified - Dual Edge | Green | Solder | -40 C | 105 ░C | |||||||
 EDAC Inc. | Polyester Thermoplastic | 2 | 3.96 mm | 0.156 in | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | Card Extender | Gold | Board Edge Straddle Mount | Dual | 0.25 Ám | 10 Áin | 36 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Semi Bellows | Female | 18 | Copper Alloy | Non Specified - Dual Edge | Green | Solder Eyelet(s) | -40 C | 105 ░C | |||
 EDAC Inc. | Polyester Thermoplastic | 2 | 3.96 mm | 0.156 in | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | Gold | Through Hole | Dual | 0.25 Ám | 10 Áin | 36 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Semi Bellows | Female | 18 | Copper Alloy | Non Specified - Dual Edge | Green | Wire Wrap | -40 C | 105 ░C | ||||
 EDAC Inc. | Polyester Thermoplastic | 2 | 3.96 mm | 0.156 in | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | Gold | Right Angle Through Hole | Dual | 0.25 Ám | 10 Áin | 36 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Semi Bellows | Female | 18 | Copper Alloy | Non Specified - Dual Edge | Green | Solder | -40 C | 105 ░C | ||||
 EDAC Inc. | Polyester Thermoplastic | 3.96 mm | 0.156 in | Tin | Through Hole | Single | 36 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Semi Bellows | Female | Copper Alloy | Non Specified - Single Edge | Green | Wire Wrap | -40 C | 105 ░C | 1 | 36 | 1 |
