845-044 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 44POS 0.100
| Part | Termination Rows [custom] | Material - Insulation | Number of Positions | Gender | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Card Type | Contact Finish Thickness | Contact Finish Thickness | Contact Material | Operating Temperature [Max] | Operating Temperature [Min] | Color | Termination | Pitch | Pitch | Card Thickness [Max] | Card Thickness [Min] | Contact Finish | Read Out | Number of Rows [custom] | Contact Type | Number of Positions/Bay/Row | Mounting Type | Termination Rows | Number of Rows | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 44 | Female | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | Copper Alloy | 125 °C | -40 C | Green | Solder Eyelet(s) | 0.1 " | 2.54 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Dual | 2 | Cantilever | 22 | Through Hole | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 44 | Female | M3 Threaded Insert Top Mount Opening | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | Copper Alloy | 125 °C | -40 C | Green | Wire Wrap | 0.1 " | 2.54 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Dual | 2 | Cantilever | 22 | Through Hole | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 44 | Female | 0.128 " | 3.25 mm | Non Specified - Single Edge | 0.25 Ám | 10 Áin | Copper Alloy | 125 °C | -40 C | Green | Solder | 0.1 " | 2.54 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Single | Cantilever | 44 | Right Angle Through Hole | 1 | 1 | ||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 44 | Female | 4-40 Threaded Insert Top Mount Opening | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | Copper Alloy | 125 °C | -40 C | Green | Solder | 0.1 " | 2.54 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Dual | 2 | Cantilever | 22 | Board Edge Straddle Mount | Card Extender | ||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 44 | Female | 4-40 Threaded Insert Top Mount Opening | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | Copper Alloy | 125 °C | -40 C | Green | Solder | 0.1 " | 2.54 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Dual | 2 | Cantilever | 22 | Through Hole | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 44 | Female | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Non Specified - Single Edge | 0.25 Ám | 10 Áin | Copper Alloy | 125 °C | -40 C | Green | Solder | 0.1 " | 2.54 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Single | Cantilever | 44 | Through Hole | 1 | 1 | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 44 | Female | M3 Threaded Insert Top Mount Opening | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | Copper Alloy | 125 °C | -40 C | Green | Solder | 0.1 " | 2.54 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Dual | 2 | Cantilever | 22 | Right Angle Through Hole | |||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 44 | Female | 4-40 Threaded Insert Top Mount Opening | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | Copper Alloy | 125 °C | -40 C | Green | Solder Eyelet(s) | 0.1 " | 2.54 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Dual | 2 | Cantilever | 22 | Through Hole | |||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 44 | Female | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | Copper Alloy | 125 °C | -40 C | Green | Solder | 0.1 " | 2.54 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Dual | 2 | Cantilever | 22 | Board Edge Straddle Mount | Card Extender | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 44 | Female | Non Specified - Single Edge | 0.25 Ám | 10 Áin | Copper Alloy | 125 °C | -40 C | Green | Solder | 0.1 " | 2.54 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Single | Cantilever | 44 | Through Hole | 1 | 1 |
