PAT-04 Series

Catalog

LCP-LCP MM OM3 2MM AQUADUPLEX 4M

Part	Type	Operating Temperature [Max]	Operating Temperature [Min]	Cable Diameter [diameter]	Cable Diameter [diameter]	Color - Connectors	1st Connector	2nd Connector	Length - Overall [x]	Length - Overall [x]	Fiber Type	Return Loss	Color - Cable	Insertion Loss	Ratings	Cable Type	Features	Return Loss [Min]	Return Loss [Max]
FiberSource, Inc PAT-04-NN-F-20-D-A	Duplex Multimode OM3	85 °C	-40 C	0.08 "	2 mm	Blue	LC/PPC	LC/PPC	4 m	13.1 ft	50/125
FiberSource, Inc PAT-04-DC-B-20-D-9	Duplex Singlemode	85 °C	-40 C	0.08 "	2 mm	Blue	SC Duplex	SC Duplex	4 m	13.1 ft	9/125	65 dB	Yellow	0.3 dB	LSZH	Bend Insensitive Fiber (BIF)	Low Smoke
FiberSource, Inc PAT-04-HH-B-20-D-9	Duplex Singlemode	85 °C	-40 C	0.08 "	2 mm	Blue	LC Duplex	LC Duplex	4 m	13.1 ft	9/125	55 dB	Yellow	0.3 dB	LSZH	Bend Insensitive Fiber (BIF)	Low Smoke
FiberSource, Inc PAT-04-HD-B-20-D-9	Duplex Singlemode	85 °C	-40 C	0.08 "	2 mm	Blue	LC Duplex	SC Duplex	4 m	13.1 ft	9/125	65 dB	Yellow	0.3 dB	LSZH	Bend Insensitive Fiber (BIF)	Low Smoke
FiberSource, Inc PAT-04-NL-F-20-D-A	Duplex Multimode OM3	85 °C	-40 C	0.08 "	2 mm	Blue	LC Duplex	SC Duplex	4 m	13.1 ft	50/125
FiberSource, Inc PAT-04-HC-B-20-D-9	Duplex Singlemode	85 °C	-40 C	0.08 "	2 mm	Blue	LC Duplex	SC Duplex	4 m	13.1 ft	9/125	55 dB	Yellow	0.3 dB	LSZH	Bend Insensitive Fiber (BIF)	Low Smoke
FiberSource, Inc PAT-04-CC-B-20-S-9	Simplex Singlemode	85 °C	-40 C	0.08 "	2 mm		SC/UPC	SC/UPC	4 m	13.1 ft	9/125		Yellow	0.2 dB	LSZH	Bend Insensitive Fiber (BIF)	Low Smoke	55 dB	65 dB
FiberSource, Inc PAT-04-DD-B-20-D-9	Duplex Singlemode	85 °C	-40 C	0.08 "	2 mm	Blue	SC Duplex	SC Duplex	4 m	13.1 ft	9/125	65 dB	Yellow	0.3 dB	LSZH	Bend Insensitive Fiber (BIF)	Low Smoke
FiberSource, Inc PAT-04-CC-B-20-D-9	Duplex Singlemode	85 °C	-40 C	0.08 "	2 mm	Blue	SC Duplex	SC Duplex	4 m	13.1 ft	9/125	55 dB	Yellow	0.3 dB	LSZH	Bend Insensitive Fiber (BIF)	Low Smoke
