15ETX06 Series

Manufacturer: Vishay General Semiconductor - Diodes Division

Catalog

DIODE GP 600V 15A TO220ACFP

Part	Technology	Voltage - DC Reverse (Vr) (Max) [Max]	Operating Temperature - Junction [Max]	Operating Temperature - Junction [Min]	Speed	Current - Reverse Leakage @ Vr	Mounting Type	Supplier Device Package	Reverse Recovery Time (trr)	Current - Average Rectified (Io)	Package / Case	Voltage - Forward (Vf) (Max) @ If [Max]	Grade	Qualification
Vishay General Semiconductor - Diodes Division 15ETX06FP	Standard	600 V	175 ░C	-65 C	200 mA 500 ns	50 µA	Through Hole	TO-220AC Full Pack	32 ns	15 A	TO-220-2 Full Pack	3.2 V
Vishay General Semiconductor - Diodes Division VS-15ETX06STRR-M3	Standard	600 V	175 ░C	-65 C	200 mA 500 ns	50 µA	Surface Mount	TO-263AB (D2PAK)	32 ns	15 A	D2PAK (2 Leads + Tab) TO-263-3 TO-263AB	3.2 V
Vishay General Semiconductor - Diodes Division VS-15ETX06SPBF	Standard	600 V	175 ░C	-65 C	200 mA 500 ns	50 µA	Surface Mount	TO-263AB (D2PAK)	22 ns	15 A	D2PAK (2 Leads + Tab) TO-263-3 TO-263AB	3.2 V	Automotive	AEC-Q101
Vishay General Semiconductor - Diodes Division VS-15ETX06FPPBF	Standard	600 V	175 ░C	-65 C	200 mA 500 ns	50 µA	Through Hole	TO-220-2 Full Pack	32 ns	15 A	TO-220-2 Full Pack	3.2 V
Vishay General Semiconductor - Diodes Division VS-15ETX06-M3	Standard	600 V	175 ░C	-65 C	200 mA 500 ns	50 µA	Through Hole	TO-220AC	32 ns	15 A	TO-220-2	3.2 V
Vishay General Semiconductor - Diodes Division 15ETX06-1	Standard	600 V	175 ░C	-65 C	200 mA 500 ns	50 µA	Through Hole	TO-262-3	32 ns	15 A	I2PAK TO-262-3 Long Leads TO-262AA	3.2 V
Vishay General Semiconductor - Diodes Division VS-15ETX06STRL-M3	Standard	600 V	175 ░C	-65 C	200 mA 500 ns	50 µA	Surface Mount	TO-263AB (D2PAK)	32 ns	15 A	D2PAK (2 Leads + Tab) TO-263-3 TO-263AB	3.2 V
