307-006 Series
Manufacturer: EDAC Inc.
Catalog
CONN EDGE SGL FML 6POS 0.156 TIN
...
| Part | Card Type | Mounting Type | Card Thickness [Min] | Card Thickness [Min] | Card Thickness [Max] | Card Thickness [Max] | Color | Number of Positions/Bay/Row [custom] | Contact Finish | Gender | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Operating Temperature [Min] | Operating Temperature [Max] | Read Out | Contact Material | Termination | Material - Insulation | Contact Type | Termination Rows | Number of Rows | Pitch [x] | Pitch [x] | Number of Positions | Features | Contact Finish Thickness | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Non Specified - Single Edge | Through Hole | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Green | 6 | Tin | Female | 3.96 mm | Flush Mount Top Opening Unthreaded | 0.156 in | -40 °C | 105 ░C | Single | Copper Alloy | Wire Wrap | Polyester Thermoplastic | Semi Bellows | 1 | 1 | 0.156 in | 3.96 mm | 6 | |||
 EDAC Inc. | Non Specified - Single Edge | Through Hole | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Green | 6 | Tin | Female | -40 °C | 105 ░C | Single | Copper Alloy | Wire Wrap | Polyester Thermoplastic | Semi Bellows | 1 | 1 | 0.156 in | 3.96 mm | 6 | ||||||
 EDAC Inc. | Non Specified - Dual Edge | Through Hole | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Green | 6 | Gold | Female | 4-40 Flush Mount Threaded Insert Top Opening | -40 °C | 105 ░C | Dual | Copper Alloy | Solder Eyelet(s) | Polyester Thermoplastic | Semi Bellows | 1 | 2 | 0.156 in | 3.96 mm | 12 | Card Guides | 10 Áin | 0.25 Ám | ||
 EDAC Inc. | Non Specified - Single Edge | Through Hole Right Angle | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Green | 6 | Tin | Female | 4-40 Flush Mount Threaded Insert Top Opening | -40 °C | 105 ░C | Single | Copper Alloy | Solder | Polyester Thermoplastic | Semi Bellows | 1 | 1 | 0.156 in | 3.96 mm | 6 | Card Guides | ||||
 EDAC Inc. | Non Specified - Dual Edge | Through Hole Right Angle | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Green | 6 | Tin | Female | 4-40 Flush Mount Threaded Insert Top Opening | -40 °C | 105 ░C | Dual | Copper Alloy | Solder | Polyester Thermoplastic | Semi Bellows | 1 | 2 | 0.156 in | 3.96 mm | 12 | |||||
 EDAC Inc. | Non Specified - Dual Edge | Through Hole Right Angle | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Green | 6 | Gold | Female | 4-40 Flush Mount Threaded Insert Top Opening | -40 °C | 105 ░C | Dual | Copper Alloy | Solder | Polyester Thermoplastic | Semi Bellows | 1 | 2 | 0.156 in | 3.96 mm | 12 | Card Guides | 10 Áin | 0.25 Ám | ||
 EDAC Inc. | Non Specified - Dual Edge | Through Hole Right Angle | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Green | 6 | Tin | Female | 4-40 Flush Mount Threaded Insert Top Opening | -40 °C | 105 ░C | Dual | Copper Alloy | Solder | Polyester Thermoplastic | Semi Bellows | 1 | 2 | 0.156 in | 3.96 mm | 12 | Card Guides | ||||
 EDAC Inc. | Non Specified - Single Edge | Through Hole | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Green | 6 | Gold | Female | 4-40 Flush Mount Threaded Insert Top Opening | -40 °C | 105 ░C | Single | Copper Alloy | Solder | Polyester Thermoplastic | Semi Bellows | 1 | 1 | 0.156 in | 3.96 mm | 6 | 10 Áin | 0.25 Ám | |||
 EDAC Inc. | Non Specified - Single Edge | Through Hole | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Green | 6 | Tin | Female | 4-40 Flush Mount Threaded Insert Top Opening | -40 °C | 105 ░C | Single | Copper Alloy | Wire Wrap | Polyester Thermoplastic | Semi Bellows | 1 | 1 | 0.156 in | 3.96 mm | 6 | Card Guides | ||||
 EDAC Inc. | Non Specified - Single Edge | Through Hole | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Green | 6 | Tin | Female | 4-40 Flush Mount Threaded Insert Top Opening | -40 °C | 105 ░C | Single | Copper Alloy | Wire Wrap | Polyester Thermoplastic | Semi Bellows | 1 | 1 | 0.156 in | 3.96 mm | 6 | Card Guides |
