892-088 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 88POS 0.100
| Part | Termination Rows [custom] | Material - Insulation | Number of Positions | Number of Positions/Bay/Row | Number of Rows [custom] | Read Out | Gender | Color | Contact Finish Thickness | Contact Finish Thickness | Operating Temperature [Max] | Operating Temperature [Min] | Contact Finish | Pitch | Pitch | Termination | Card Type | Contact Type | Flange Feature | Mounting Type | Contact Material | Card Thickness [Max] | Card Thickness [Min] | Features | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 88 | 44 | 2 | Dual | Female | Black | 0.25 Ám | 10 Áin | 125 °C | -40 C | Gold | 0.1 " | 2.54 mm | Wire Wrap | Non Specified - Dual Edge | Cantilever | Flush Mount M3 Threaded Insert Top Opening | Through Hole | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 88 | 44 | 2 | Dual | Female | Black | 0.25 Ám | 10 Áin | 125 °C | -40 C | Gold | 0.1 " | 2.54 mm | Solder | Non Specified - Dual Edge | Cantilever | Flush Mount Side Opening Unthreaded | Board Edge Straddle Mount | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Card Extender | 0.128 " | 3.25 mm |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 88 | 44 | 2 | Dual | Female | Black | 0.25 Ám | 10 Áin | 125 °C | -40 C | Gold | 0.1 " | 2.54 mm | Solder | Non Specified - Dual Edge | Cantilever | Flush Mount M3 Threaded Insert Top Opening | Through Hole | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 88 | 44 | 2 | Dual | Female | Black | 0.25 Ám | 10 Áin | 125 °C | -40 C | Gold | 0.1 " | 2.54 mm | Solder Eyelet(s) | Non Specified - Dual Edge | Cantilever | Flush Mount Top Opening Unthreaded | Through Hole | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.128 " | 3.25 mm | |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 88 | 44 | 2 | Dual | Female | Black | 0.25 Ám | 10 Áin | 125 °C | -40 C | Gold | 0.1 " | 2.54 mm | Solder | Non Specified - Dual Edge | Cantilever | Board Edge Straddle Mount | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Card Extender | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 88 | 44 | 2 | Dual | Female | Black | 0.25 Ám | 10 Áin | 125 °C | -40 C | Gold | 0.1 " | 2.54 mm | Solder | Non Specified - Dual Edge | Cantilever | Floating Bobbin Flush Mount | Through Hole | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.116 " | 2.95 mm | |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 88 | 44 | 2 | Dual | Female | Black | 0.25 Ám | 10 Áin | 125 °C | -40 C | Gold | 0.1 " | 2.54 mm | Solder | Non Specified - Dual Edge | Cantilever | Through Hole | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | ||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 88 | 44 | 2 | Dual | Female | Black | 0.25 Ám | 10 Áin | 125 °C | -40 C | Gold | 0.1 " | 2.54 mm | Wire Wrap | Non Specified - Dual Edge | Cantilever | 4-40 Flush Mount Threaded Insert Top Opening | Through Hole | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 88 | 44 | 2 | Dual | Female | Black | 0.25 Ám | 10 Áin | 125 °C | -40 C | Gold | 0.1 " | 2.54 mm | Wire Wrap | Non Specified - Dual Edge | Cantilever | Flush Mount Top Opening Unthreaded | Through Hole | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.128 " | 3.25 mm | |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 88 | 44 | 2 | Dual | Female | Black | 0.25 Ám | 10 Áin | 125 °C | -40 C | Gold | 0.1 " | 2.54 mm | Solder | Non Specified - Dual Edge | Cantilever | Flush Mount Side Opening Unthreaded | Through Hole | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.128 " | 3.25 mm |
