BH015 Series
Manufacturer: GCT
Beta
⌘K
BOARD TO BOARD & MEZZANINE CONNECTORS 12W, 3.96MM PITCH SOCKET, SMT, VERTICAL, TIN, TUBE/CAP
| Part | Contact Shape | Insulation Material | Contact Material | Fastening Type | Contact Type | Termination | Current Rating (Amps) | Features | Contact Finish - Post | Connector Type | Mounting Type | Number of Rows | Pitch - Mating | Pitch - Mating | Material Flammability Rating | Operating Temperature [Min] | Operating Temperature [Max] | Insulation Height | Insulation Height | Insulation Color | Number of Positions | Number of Positions Loaded |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 GCT | Square | Liquid Crystal Polymer (LCP) | Phosphor Bronze | Push-Pull | Female Socket | Solder | 7.9 A | Pick and Place | Tin | Receptacle Bottom or Top Entry | Surface Mount | 1 | 3.96 mm | 0.156 in | UL94 V-0 | -40 C | 105 ░C | 8.89 mm | 0.35 in | Black | 12 | All |
GCT | Square | Liquid Crystal Polymer (LCP) | Phosphor Bronze | Push-Pull | Female Socket | Solder | 7.9 A | Pick and Place | Tin | Receptacle Bottom or Top Entry | Surface Mount | 1 | 3.96 mm | 0.156 in | UL94 V-0 | -40 C | 105 ░C | 8.89 mm | 0.35 in | Black | 6 | All |
 GCT | Push-Pull | Female Socket | Solder | 7.9 A | Pick and Place | Tin | Receptacle Bottom or Top Entry | Surface Mount | 1 | 3.96 mm | 0.156 in | UL94 V-0 | -40 C | 105 ░C | 8.89 mm | 0.35 in | Black | 4 | All |
