YB15KK Series
Manufacturer: NKK Switches
Beta
⌘K
SWITCH PUSHBUTTON SPDT 3A 125V
| Part | Mechanical Life | Electrical Life | Voltage Rating - DC | Circuit | Illumination Type, Color | Type | Illumination Voltage (Nominal) | Features | Mounting Type | Current Rating (Amps) | Termination Style | Color - Actuator/Cap | Actuator Marking | Operating Temperature [Max] | Operating Temperature [Min] | Voltage Rating - AC | Panel Cutout Dimensions [diameter] | Actuator Type | Switch Function |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NKK Switches | 1000000 Cycles | 100000 Cycles | 30 V | SPDT | LED Red | Illuminated Standard | 5 VDC | Stainless Steel | Panel Mount Snap-In | 3 A | PC Pin | Clear | No Marking | 50 °C | -25 °C | 125 V | 16 mm | Button Square | On-Mom |
 NKK Switches | 1000000 Cycles | 100000 Cycles | 30 V | SPDT | Standard | Stainless Steel | Panel Mount Snap-In | 3 A | Solder Quick Connect - 0.110" (2.8mm) | White | No Marking | 70 °C | -25 °C | 125 V | 16 mm | Button Square | On-Mom | ||
 NKK Switches | 1000000 Cycles | 100000 Cycles | 28 V | SPDT | Standard | Stainless Steel | Panel Mount Snap-In | 0.4 VA | Solder Quick Connect - 0.110" (2.8mm) | No Marking | 70 °C | -25 °C | 28 V | 16 mm | Plunger for Cap | On-Mom | |||
NKK Switches | 1000000 Cycles | 100000 Cycles | 28 V | SPDT | Standard | Stainless Steel | Panel Mount Snap-In | 0.4 VA | Solder Quick Connect - 0.110" (2.8mm) | Clear | No Marking | 70 °C | -25 °C | 28 V | 16 mm | Button Square | On-Mom | ||
NKK Switches | 1000000 Cycles | 100000 Cycles | 30 V | SPDT | Green LED | Illuminated Standard | 5 VDC | Panel Mount Snap-In | 3 A | Solder Quick Connect - 0.110" (2.8mm) | Clear | 50 °C | -25 °C | 125 V | 16 mm | Button Square | On-Mom | ||
NKK Switches | 1000000 Cycles | 100000 Cycles | 30 V | SPDT | Standard | Stainless Steel | Panel Mount Snap-In | 3 A | PC Pin | No Marking | 70 °C | -25 °C | 125 V | 16 mm | Plunger for Cap | On-Mom | |||
NKK Switches | 1000000 Cycles | 100000 Cycles | 30 V | SPDT | Green LED | Illuminated Standard | 2.2 VDC | Stainless Steel | Panel Mount Snap-In | 3 A | Solder Quick Connect - 0.110" (2.8mm) | Clear | No Marking | 50 °C | -25 °C | 125 V | 16 mm | Button Square | On-Mom |
NKK Switches | 1000000 Cycles | 100000 Cycles | 30 V | SPDT | Amber LED | Illuminated Standard | 2 VDC | Stainless Steel | Panel Mount Snap-In | 3 A | Solder Quick Connect - 0.110" (2.8mm) | Clear | No Marking | 50 °C | -25 °C | 125 V | 16 mm | Button Square | On-Mom |
NKK Switches | 1000000 Cycles | 100000 Cycles | 30 V | SPDT | Green/Red LED | Illuminated Standard | 5 VDC | Stainless Steel | Panel Mount Snap-In | 3 A | Solder Quick Connect - 0.110" (2.8mm) | Clear | No Marking | 50 °C | -25 °C | 125 V | 16 mm | Button Square | On-Mom |
NKK Switches | 1000000 Cycles | 100000 Cycles | 30 V | SPDT | LED Red | Illuminated Standard | 1.9 VDC | Stainless Steel | Panel Mount Snap-In | 3 A | Solder Quick Connect - 0.110" (2.8mm) | Clear | No Marking | 50 °C | -25 °C | 125 V | 16 mm | Button Square | On-Mom |
