895-027 Series
Manufacturer: EDAC Inc.
Catalog
CONN EDGE SINGLE FML 27POS 0.100
...
| Part | Termination Rows | Material - Insulation | Read Out | Number of Positions | Card Thickness [Max] | Card Thickness [Min] | Contact Type | Number of Positions/Bay/Row | Termination | Contact Material | Contact Finish Thickness | Contact Finish Thickness | Number of Rows | Pitch | Pitch | Mounting Type | Card Type | Operating Temperature [Max] | Operating Temperature [Min] | Contact Finish | Color | Gender | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Single | 27 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 27 | Solder | Copper Alloy | 0.25 Ám | 10 Áin | 1 | 0.1 " | 2.54 mm | Through Hole | Non Specified - Single Edge | 125 °C | -40 C | Gold | Black | Female | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Single | 27 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 27 | Wire Wrap | Copper Alloy | 0.25 Ám | 10 Áin | 1 | 0.1 " | 2.54 mm | Through Hole | Non Specified - Single Edge | 125 °C | -40 C | Gold | Black | Female | 0.128 " | 3.25 mm | |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Single | 27 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 27 | Solder Eyelet(s) | Copper Alloy | 0.25 Ám | 10 Áin | 1 | 0.1 " | 2.54 mm | Through Hole | Non Specified - Single Edge | 125 °C | -40 C | Gold | Black | Female | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Single | 27 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 27 | Solder | Copper Alloy | 0.25 Ám | 10 Áin | 1 | 0.1 " | 2.54 mm | Through Hole | Non Specified - Single Edge | 125 °C | -40 C | Gold | Black | Female | |||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Single | 27 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 27 | Solder | Copper Alloy | 0.25 Ám | 10 Áin | 1 | 0.1 " | 2.54 mm | Through Hole | Non Specified - Single Edge | 125 °C | -40 C | Gold | Black | Female | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Single | 27 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 27 | Solder | Copper Alloy | 0.25 Ám | 10 Áin | 1 | 0.1 " | 2.54 mm | Through Hole | Non Specified - Single Edge | 125 °C | -40 C | Gold | Black | Female | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Single | 27 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 27 | Solder | Copper Alloy | 0.25 Ám | 10 Áin | 1 | 0.1 " | 2.54 mm | Through Hole | Non Specified - Single Edge | 125 °C | -40 C | Gold | Black | Female | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Single | 27 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 27 | Wire Wrap | Copper Alloy | 0.25 Ám | 10 Áin | 1 | 0.1 " | 2.54 mm | Through Hole | Non Specified - Single Edge | 125 °C | -40 C | Gold | Black | Female | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Single | 27 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 27 | Wire Wrap | Copper Alloy | 0.25 Ám | 10 Áin | 1 | 0.1 " | 2.54 mm | Through Hole | Non Specified - Single Edge | 125 °C | -40 C | Gold | Black | Female | Flush Mount M3 Threaded Insert Top Opening | ||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Single | 27 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 27 | Solder | Copper Alloy | 0.25 Ám | 10 Áin | 1 | 0.1 " | 2.54 mm | Through Hole | Non Specified - Single Edge | 125 °C | -40 C | Gold | Black | Female | M3 Threaded Insert Top Mount Opening |
