845-007 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 7POS 0.100
| Part | Termination Rows | Material - Insulation | Number of Positions/Bay/Row | Operating Temperature [Max] | Operating Temperature [Min] | Card Thickness [Max] | Card Thickness [Min] | Contact Finish | Mounting Type | Color | Number of Positions | Contact Type | Termination | Contact Finish Thickness | Contact Finish Thickness | Card Type | Pitch | Pitch | Flange Feature [diameter] | Flange Feature [diameter] | Contact Material | Number of Rows | Gender | Read Out | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 7 | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Through Hole | Green | 7 | Cantilever | Solder | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 0.1 " | 2.54 mm | 3.25 mm | 0.128 " | Copper Alloy | 1 | Female | Single | |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 7 | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Right Angle Through Hole | Green | 7 | Cantilever | Solder | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 0.1 " | 2.54 mm | 3.25 mm | 0.128 " | Copper Alloy | 1 | Female | Single | Flush Mount Side Opening Unthreaded |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 7 | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Through Hole | Green | 7 | Cantilever | Solder | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 0.1 " | 2.54 mm | 3.25 mm | 0.128 " | Copper Alloy | 1 | Female | Single | Side Mount Opening Unthreaded |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 7 | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Right Angle Through Hole | Green | 7 | Cantilever | Solder | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 0.1 " | 2.54 mm | Copper Alloy | 1 | Female | Single | M3 Threaded Insert Top Mount Opening | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 7 | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Through Hole | Green | 7 | Cantilever | Wire Wrap | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 0.1 " | 2.54 mm | 3.96 mm | 0.156 " | Copper Alloy | 1 | Female | Single | Flush Mount Top Opening Unthreaded |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 7 | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Through Hole | Green | 7 | Cantilever | Solder Eyelet(s) | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 0.1 " | 2.54 mm | 3.96 mm | 0.156 " | Copper Alloy | 1 | Female | Single | Flush Mount Top Opening Unthreaded |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 7 | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Right Angle Through Hole | Green | 7 | Cantilever | Solder | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 0.1 " | 2.54 mm | 3.25 mm | 0.128 " | Copper Alloy | 1 | Female | Single | |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 7 | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Right Angle Through Hole | Green | 7 | Cantilever | Solder | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 0.1 " | 2.54 mm | 2.95 mm | 0.116 " | Copper Alloy | 1 | Female | Single | Floating Bobbin Top Mount Opening |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 7 | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Through Hole | Green | 7 | Cantilever | Solder | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 0.1 " | 2.54 mm | Copper Alloy | 1 | Female | Single | M3 Threaded Insert Top Mount Opening | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 7 | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Through Hole | Green | 7 | Cantilever | Solder | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 0.1 " | 2.54 mm | 3.25 mm | 0.128 " | Copper Alloy | 1 | Female | Single | Side Mount Opening Unthreaded |
