8502 Series

Catalog

HOOKUP STRND 20AWG WHT/BLU

Part	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Jacket Color	Length	Length	Conductor Strand [custom]	Conductor Strand [custom]	Qualification	Operating Temperature [Min]	Operating Temperature [Max]	Jacket (Insulation) Material	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Conductor Material	Voltage	Cable Type	Wire Gauge	Length [x]	Length [x]
Belden Inc. 8502 0181000	0.058 in	1.47 mm	White Blue Stripe	304.8 m	1000 ft	28 AWG	7	MIL-W-16878/1 Type B	-40 C	105 ░C	Poly-Vinyl Chloride (PVC)	0.25 mm	0.01 in	Copper Tinned	600 V	Hook-Up	20 AWG
Belden Inc. 8502 005100	0.058 in	1.47 mm	Green			28 AWG	7	MIL-W-16878/1 Type B	-40 C	105 ░C	Poly-Vinyl Chloride (PVC)	0.25 mm	0.01 in	Copper Tinned	600 V	Hook-Up	20 AWG	100 ft	30.5 m
Belden Inc. 8502 0091000	0.058 in	1.47 mm	White	304.8 m	1000 ft	28 AWG	7	MIL-W-16878/1 Type B	-40 C	105 ░C	Poly-Vinyl Chloride (PVC)	0.25 mm	0.01 in	Copper Tinned	600 V	Hook-Up	20 AWG
Belden Inc. 8502 007100	0.058 in	1.47 mm	Violet			28 AWG	7	MIL-W-16878/1 Type B	-40 C	105 ░C	Poly-Vinyl Chloride (PVC)	0.25 mm	0.01 in	Copper Tinned	600 V	Hook-Up	20 AWG	100 ft	30.5 m
Belden Inc. 8502 0061000	0.058 in	1.47 mm	Blue	304.8 m	1000 ft	28 AWG	7	MIL-W-16878/1 Type B	-40 C	105 ░C	Poly-Vinyl Chloride (PVC)	0.25 mm	0.01 in	Copper Tinned	600 V	Hook-Up	20 AWG
Belden Inc. 8502 001100	0.058 in	1.47 mm	Brown			28 AWG	7	MIL-W-16878/1 Type B	-40 C	105 ░C	Poly-Vinyl Chloride (PVC)	0.25 mm	0.01 in	Copper Tinned	600 V	Hook-Up	20 AWG	100 ft	30.5 m
Belden Inc. 8502 002100	0.058 in	1.47 mm	Red			28 AWG	7	MIL-W-16878/1 Type B	-40 C	105 ░C	Poly-Vinyl Chloride (PVC)	0.25 mm	0.01 in	Copper Tinned	600 V	Hook-Up	20 AWG	100 ft	30.5 m
Belden Inc. 8502 003100	0.058 in	1.47 mm	Orange			28 AWG	7	MIL-W-16878/1 Type B	-40 C	105 ░C	Poly-Vinyl Chloride (PVC)	0.25 mm	0.01 in	Copper Tinned	600 V	Hook-Up	20 AWG	100 ft	30.5 m
Belden Inc. 8502 004100	0.058 in	1.47 mm	Yellow			28 AWG	7	MIL-W-16878/1 Type B	-40 C	105 ░C	Poly-Vinyl Chloride (PVC)	0.25 mm	0.01 in	Copper Tinned	600 V	Hook-Up	20 AWG	100 ft	30.5 m
Belden Inc. 8502 006100	0.058 in	1.47 mm	Blue			28 AWG	7	MIL-W-16878/1 Type B	-40 C	105 ░C	Poly-Vinyl Chloride (PVC)	0.25 mm	0.01 in	Copper Tinned	600 V	Hook-Up	20 AWG	100 ft	30.5 m
