G3VM-63 Series
Manufacturer: Omron Electronics Inc-EMC Div
Beta
⌘K
SS 1FORMB RELAY 1.2A@60V SMT
| Part | On-State Resistance (Max) [Max] | Voltage - Load [Min] | Voltage - Load [Max] | Operating Temperature [Max] | Operating Temperature [Min] | Package / Case | Package / Case | Package / Case | Supplier Device Package | Load Current | Mounting Type | Termination Style | Output Type | Circuit |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Omron Electronics Inc-EMC Div | 600 mOhm | 0 V | 60 V | 85 °C | -40 °C | 7.62 mm | 0.3 in | 6-SMD | 6-SMD | 1.2 A | Surface Mount | PC Pin | AC DC | SPST-NC (1 Form B) |
 Omron Electronics Inc-EMC Div | 600 mOhm | 0 V | 60 V | 85 °C | -40 °C | 1.2 A | Surface Mount | Gull Wing | AC DC | SPST-NC (1 Form B) | ||||
 Omron Electronics Inc-EMC Div | 600 mOhm | 0 V | 60 V | 85 °C | -40 °C | 1.2 A | Through Hole | PC Pin | AC DC | SPST-NC (1 Form B) |
