M50 Series
Manufacturer: Sensata-Crydom
Beta
⌘K
DISCRETE SEMICONDUCTOR MODULES SCR/DIODE MODULE 240VAC 50ADC 600VP
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Mounting Type | Package / Case | Voltage - Off State | Number of SCRs, Diodes [custom] | Number of SCRs, Diodes [custom] | Current - Non Rep. Surge 50, 60Hz (Itsm) | Current - Gate Trigger (Igt) (Max) [Max] | Structure | Voltage - Forward (Vf) (Max) @ If | Operating Temperature - Junction [Min] | Operating Temperature - Junction [Max] | Supplier Device Package | Speed [Min] | Diode Configuration | Technology | Current - Average Rectified (Io) (per Diode) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Sensata-Crydom | -40 C | 125 °C | Chassis Mount | Module | 600 V | 2 | 2 | 600 A | 150 mA | Bridge Single Phase - SCRs/Diodes (Layout 1) | ||||||||
 Sensata-Crydom | -40 C | 125 °C | Chassis Mount | Module | 1.2 kV | 2 | 2 | 1500 A | 150 mA | Bridge Single Phase - SCRs/Diodes (Layout 1) | ||||||||
 Sensata-Crydom | Chassis Mount | Module | 1.2 V | -40 °C | 125 °C | Module | 200 mA 500 ns | 3 Common Anode | Standard | 100 A |
