1377174 Series

Manufacturer: TE Connectivity AMP Connectors

Catalog

SMP 0-0165616-5

Part	Insulation Diameter [diameter]	Insulation Diameter [diameter]	Tab Width	Tab Width	Contact Finish	Tab Thickness	Tab Thickness	Wire Gauge [Min]	Wire Gauge [Max]	Gender	Color	Terminal Type	Contact Material	Length - Overall [x]	Length - Overall [x]	Tab Length [x]	Tab Length [x]	Insulation	Termination	Mounting Type	Insulation Diameter [Max] [diameter]	Insulation Diameter [Min] [diameter]	Insulation Diameter [Max] [diameter]	Insulation Diameter [Min] [diameter]	Insulation Diameter [Min]	Insulation Diameter [Max]	Insulation Diameter [Max]	Insulation Diameter [Min]	Length - Overall	Length - Overall	Tab Length	Tab Length	Tab Width [x]	Tab Width [x]	Convert From (Adapter End)	Convert From (Adapter End)	Convert From (Adapter End)	Convert From (Adapter End)	Convert To (Adapter End)	Convert To (Adapter End)	Convert To (Adapter End)	Tab Thickness [custom]
TE Connectivity AMP Connectors 9-1377174-6	0.169 in	4.29 mm	0.11 "	2.79 mm	Tin	0.02 in	0.51 mm	14 AWG	16 AWG	Female	Blue	Standard	Phosphor Bronze	0.78 in	19.81 mm	6.3 mm	0.248 "	Non-Mating End Insulated	Crimp	Free Hanging (In-Line)
TE Connectivity AMP Connectors 7-1377174-7			0.11 "	2.79 mm	Tin	0.032 in	0.81 mm	22 AWG	26 AWG	Female	Yellow	Standard	Brass			6.3 mm	0.248 "	Non-Mating End Insulated	Crimp	Free Hanging (In-Line)	0.083 "	0.043 "	2.11 mm	1.1 mm
TE Connectivity AMP Connectors 8-1377174-7					Tin	0.032 in	0.81 mm	16 AWG	22 AWG	Female	Red	Standard	Brass					Non-Mating End Insulated	Crimp	Free Hanging (In-Line)					2.67 mm	0.14 in	3.56 mm	0.105 in	0.822 in	20.88 mm	0.25 in	6.35 mm	0.187 in	4.75 mm
TE Connectivity AMP Connectors 5-1377174-1						0.032 in	0.81 mm			Male		Angled - 45°	Brass					Non-Insulated	Rivet Screw Stud	Board Chassis											0.311 in	7.9 mm	0.25 in	6.35 mm
TE Connectivity AMP Connectors 6-1377174-2						0.032 in	0.81 mm			Male		Angled - 45°	Brass					Non-Insulated	Rivet Screw Stud	Board Chassis											0.307 "	7.8 mm	0.25 in	6.35 mm
TE Connectivity AMP Connectors 9-1377174-5	0.169 in	4.29 mm	0.11 "	2.79 mm	Tin	0.02 in	0.51 mm	14 AWG	16 AWG	Female	Blue	Standard	Brass	0.78 in	19.81 mm			Non-Mating End Insulated	Crimp	Free Hanging (In-Line)											0.25 in	6.35 mm
TE Connectivity AMP Connectors 6-1377174-7																		Insulated																	Quick Connect Male	0.25 in 2 Rows	6.35 mm	0.25 in	1/4" Quick Connect Male (2)	0.25 in	0.25 in
TE Connectivity AMP Connectors 9-1377174-5			0.11 "	2.79 mm	Tin	0.02 in	0.51 mm	14 AWG	16 AWG	Female	Blue	Standard	Brass	0.78 in	19.81 mm			Non-Mating End Insulated	Crimp	Free Hanging (In-Line)											0.25 in	6.35 mm
TE Connectivity AMP Connectors 9-1377174-0			0.197 "	5 mm	Tin	0.032 in	0.81 mm	17 AWG	22 AWG	Female	Blue	Standard	Phosphor Bronze					Non-Mating End Insulated	Crimp	Free Hanging (In-Line)
TE Connectivity AMP Connectors 8-1377174-0	0.14 in	3.56 mm	0.11 "	2.79 mm	Tin		0.41 mm	16 AWG	22 AWG	Female	Red	Standard	Brass	0.78 in	19.81 mm	6.3 mm	0.248 "	Non-Mating End Insulated	Crimp	Free Hanging (In-Line)																						0.016 in
