807-034 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 34POS 0.156
| Part | Material - Insulation | Termination Rows [custom] | Termination | Pitch | Pitch | Color | Contact Material | Contact Type | Number of Positions/Bay/Row [custom] | Gender | Read Out | Contact Finish Thickness | Contact Finish Thickness | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Number of Rows [custom] | Mounting Type | Contact Finish | Operating Temperature [Max] | Operating Temperature [Min] | Card Type | Card Thickness [Max] | Card Thickness [Min] | Number of Positions [custom] | Termination Rows | Number of Positions/Bay/Row | Number of Rows | Number of Positions |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Solder | 3.96 mm | 0.156 in | Green | Copper Alloy | Semi Bellows | 17 | Female | Single | 0.25 Ám | 10 Áin | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | 2 | Right Angle Through Hole | Gold | 125 °C | -40 C | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 34 | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Solder | 3.96 mm | 0.156 in | Green | Copper Alloy | Semi Bellows | 17 | Female | Single | 0.25 Ám | 10 Áin | 2 | Right Angle Through Hole | Gold | 125 °C | -40 C | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 34 | |||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Solder | 3.96 mm | 0.156 in | Green | Copper Alloy | Semi Bellows | Female | Single | 0.25 Ám | 10 Áin | Through Hole | Gold | 125 °C | -40 C | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 34 | 1 | 34 | 1 | |||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Wire Wrap | 3.96 mm | 0.156 in | Green | Copper Alloy | Semi Bellows | 17 | Female | Dual | 0.25 Ám | 10 Áin | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | 2 | Through Hole | Gold | 125 °C | -40 C | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 34 | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Solder Eyelet(s) | 3.96 mm | 0.156 in | Green | Copper Alloy | Semi Bellows | 17 | Female | Dual | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | 2 | Through Hole | Tin | 125 °C | -40 C | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 34 | ||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Solder | 3.96 mm | 0.156 in | Green | Copper Alloy | Semi Bellows | 17 | Female | Single | 2 | Right Angle Through Hole | Tin | 125 °C | -40 C | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 34 | |||||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Solder Eyelet(s) | 3.96 mm | 0.156 in | Green | Copper Alloy | Semi Bellows | Female | Dual | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | 2 | Through Hole | Tin | 125 °C | -40 C | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 34 | 68 positions | ||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Solder Eyelet(s) | 3.96 mm | 0.156 in | Green | Copper Alloy | Semi Bellows | Female | Dual | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | 2 | Through Hole | Tin | 125 °C | -40 C | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 34 | 68 positions | ||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Solder | 3.96 mm | 0.156 in | Green | Copper Alloy | Semi Bellows | Female | Dual | 0.25 Ám | 10 Áin | 2 | Right Angle Through Hole | Gold | 125 °C | -40 C | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 34 | 68 positions | |||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Wire Wrap | 3.96 mm | 0.156 in | Green | Copper Alloy | Semi Bellows | 17 | Female | Dual | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | 2 | Through Hole | Tin | 125 °C | -40 C | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 34 |
