3SU1133 Series

Manufacturer: Siemens

Catalog

ILLUMINATED PUSHBUTTON, MOM, RED

Part	Electrical Life	Mechanical Life	Actuator Type	Illumination Type, Color	Operating Temperature [Min]	Operating Temperature [Max]	Switch Function	Type	Termination Style	Current Rating (Amps)	Ingress Protection	Color - Actuator/Cap	Panel Cutout Dimensions [diameter]	Illumination Voltage (Nominal)	Mounting Type	Voltage Rating - AC	Circuit	Voltage Rating - DC
Siemens 3SU11330AB201CA0	10000000 Cycles	3000000 Cycles	Button Round	LED Red	-25 °C	70 °C	On-Mom	Illuminated Standard	Screw Terminal	10 A	IP66 IP67 IP69K	Red	22.3 mm	110 VAC	Panel Mount Front	500 V	SPST-NC	500 V
Siemens 3SU11330AB601FA0	10000000 Cycles	3000000 Cycles	Button Round	LED White	-25 °C	70 °C	Off-Mom On-Mom	Illuminated Standard	Screw Terminal	10 A	IP66 IP67 IP69K	White	22.3 mm	110 VAC	Panel Mount Front	500 V	DPST-NO/NC	500 V
Siemens 3SU11330AB401FA0	10000000 Cycles	3000000 Cycles	Button Round	Green LED	-25 °C	70 °C	Off-Mom On-Mom	Illuminated Standard	Screw Terminal	10 A	IP66 IP67 IP69K	Green	22.3 mm	110 VAC	Panel Mount Front	500 V	DPST-NO/NC	500 V
Siemens 3SU11330AB701BA0	10000000 Cycles	3000000 Cycles	Button Round	LED White	-25 °C	70 °C	Off-Mom	Illuminated Standard	Screw Terminal	10 A	IP66 IP67 IP69K	Clear	22.3 mm	110 VAC	Panel Mount Front	500 V	SPST-NO	500 V
Siemens 3SU11330AB701FA0	10000000 Cycles	3000000 Cycles	Button Round	LED White	-25 °C	70 °C	Off-Mom On-Mom	Illuminated Standard	Screw Terminal	10 A	IP66 IP67 IP69K	Clear	22.3 mm	110 VAC	Panel Mount Front	500 V	DPST-NO/NC	500 V
Siemens 3SU11330AB401BA0	10000000 Cycles	3000000 Cycles	Button Round	Green LED	-25 °C	70 °C	Off-Mom	Illuminated Standard	Screw Terminal	10 A	IP66 IP67 IP69K	Green	22.3 mm	110 VAC	Panel Mount Front	500 V	SPST-NO	500 V
Siemens 3SU11330AB301FA0	10000000 Cycles	3000000 Cycles	Button Round	LED Yellow	-25 °C	70 °C	Off-Mom On-Mom	Illuminated Standard	Screw Terminal	10 A	IP66 IP67 IP69K	Yellow	22.3 mm	110 VAC	Panel Mount Front	500 V	DPST-NO/NC	500 V
Siemens 3SU11330AB501FA0	10000000 Cycles	3000000 Cycles	Button Round	Blue LED	-25 °C	70 °C	Off-Mom On-Mom	Illuminated Standard	Screw Terminal	10 A	IP66 IP67 IP69K	Blue	22.3 mm	110 VAC	Panel Mount Front	500 V	DPST-NO/NC	500 V
Siemens 3SU11330AB301BA0	10000000 Cycles	3000000 Cycles	Button Round	LED Yellow	-25 °C	70 °C	Off-Mom	Illuminated Standard	Screw Terminal	10 A	IP66 IP67 IP69K	Yellow	22.3 mm	110 VAC	Panel Mount Front	500 V	SPST-NO	500 V
Siemens 3SU11330AB501BA0	10000000 Cycles	3000000 Cycles	Button Round	Blue LED	-25 °C	70 °C	Off-Mom	Illuminated Standard	Screw Terminal	10 A	IP66 IP67 IP69K	Blue	22.3 mm	110 VAC	Panel Mount Front	500 V	SPST-NO	500 V
