C14610N016 Series

Manufacturer: Amphenol Tuchel Industrial

Catalog

CONN BASE SIDE ENTRY SZE16 M32

Part	Operating Temperature [Min]	Operating Temperature [Max]	Thread Size	Lock Location	Style	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Connector Type	Housing Material	Size	Ingress Protection	Features
Amphenol Tuchel Industrial C14610N0166042	-40 C	100 °C	M32	Locking Clip (2) on Hood	Side Entry	4.606 in	77 mm	57 mm	3.031 "	2.244 "	117 mm	Base - Box Mount	Aluminum Alloy Die Cast	E16	IP65 - Dust Tight Water Resistant
Amphenol Tuchel Industrial C14610N0166012	-40 C	100 °C	M25	Locking Clip (2) on Base Bottom	Side Entry	4.606 in	77 mm	57 mm	3.031 "	2.244 "	117 mm	Base - Box Mount	Aluminum Alloy Die Cast	E16	IP65 - Dust Tight Water Resistant	Feed Through
Amphenol Tuchel Industrial C14610N0165002	-40 C	100 °C	M32	Locking Clip (2) on Base Bottom	Side Entry	4.606 in	77 mm	57 mm	3.031 "	2.244 "	117 mm	Base - Box Mount	Aluminum Alloy Die Cast	E16	IP65 - Dust Tight Water Resistant
Amphenol Tuchel Industrial C14610N0166072	-40 C	100 °C	M25	Locking Clip (1) on Base Bottom	Side Entry	4.606 in	77 mm	57 mm	3.031 "	2.244 "	117 mm	Base - Box Mount	Aluminum Alloy Die Cast	E16	IP65 - Dust Tight Water Resistant
Amphenol Tuchel Industrial C14610N0166002	-40 C	100 °C	M32	Locking Clip (2) on Base Bottom	Side Entry	4.606 in	77 mm	57 mm	3.031 "	2.244 "	117 mm	Base - Box Mount	Aluminum Alloy Die Cast	E16	IP65 - Dust Tight Water Resistant	Feed Through
Amphenol Tuchel Industrial C14610N0168041	-40 C	100 °C	M25	Locking Clip (2) on Hood	Side Entry	4.606 in	64 mm	57 mm	2.52 in	2.244 "	117 mm	Base - Box Mount	Aluminum Alloy Die Cast	E16	IP65 - Dust Tight Water Resistant	Cover
Amphenol Tuchel Industrial C14610N0166041	-40 C	100 °C	M25	Locking Clip (2) on Hood	Side Entry	4.606 in	64 mm	57 mm	2.52 in	2.244 "	117 mm	Base - Box Mount	Aluminum Alloy Die Cast	E16	IP65 - Dust Tight Water Resistant
Amphenol Tuchel Industrial C14610N0168042	-40 C	100 °C	M32	Locking Clip (2) on Hood	Side Entry	4.606 in	77 mm	57 mm	3.031 "	2.244 "	117 mm	Base - Box Mount	Aluminum Alloy Die Cast	E16	IP65 - Dust Tight Water Resistant	Cover
Amphenol Tuchel Industrial C14610N0168062	-40 C	100 °C	M32	Locking Clip (1) on Base Bottom	Side Entry	4.606 in	77 mm	57 mm	3.031 "	2.244 "	117 mm	Base - Box Mount	Aluminum Alloy Die Cast	E16	IP65 - Dust Tight Water Resistant	Cover
Amphenol Tuchel Industrial C14610N0166061	-40 C	100 °C	M25	Locking Clip (1) on Base Bottom	Side Entry	4.606 in	64 mm	57 mm	2.52 in	2.244 "	117 mm	Base - Box Mount	Aluminum Alloy Die Cast	E16	IP65 - Dust Tight Water Resistant
