R40477 Series
Manufacturer: Radiall USA, Inc.
Beta
⌘K
TERMINATION: SMA M 6 GHZ 100W
| Part | Dielectric Material | Body Material | Contact Finish | Mounting Type | Impedance | Connector Type | Connector Style | Frequency - Max [Max] | Contact Material | Body Finish |
|---|---|---|---|---|---|---|---|---|---|---|
 Radiall USA, Inc. | Polytetrafluoroethylene (PTFE) | Stainless Steel | Gold | Cap Free Hanging | 50 Ohms | Plug Male Pin | SMA | 6000 MHz | Beryllium Copper | |
 Radiall USA, Inc. | Polytetrafluoroethylene (PTFE) | Stainless Steel | Gold | Cap Free Hanging | 50 Ohms | Female Socket Jack | TNC | 6000 MHz | Beryllium Copper | |
 Radiall USA, Inc. | Polytetrafluoroethylene (PTFE) | Stainless Steel | Gold | Panel Mount Square Flange | 50 Ohms | Female Socket Jack | SMA | 6000 MHz | Beryllium Copper | |
 Radiall USA, Inc. | Polytetrafluoroethylene (PTFE) | Stainless Steel | Gold | Cap Free Hanging | 50 Ohms | Female Socket Jack | SMA | 6000 MHz | Beryllium Copper | |
 Radiall USA, Inc. | Polytetrafluoroethylene (PTFE) | Stainless Steel | Gold | Panel Mount Square Flange | 50 Ohms | Plug Male Pin | SMA | 6000 MHz | Beryllium Copper | |
 Radiall USA, Inc. | Polytetrafluoroethylene (PTFE) | Brass | Gold | Cap Free Hanging | 50 Ohms | Female Socket Jack | 4.3/10 | 6000 MHz | Beryllium Copper | Nickel |
 Radiall USA, Inc. | Polytetrafluoroethylene (PTFE) | Brass | Gold | Cap Free Hanging | 50 Ohms | Female Socket Jack | N Type | 6000 MHz | Beryllium Copper | White Bronze |
 Radiall USA, Inc. | Polytetrafluoroethylene (PTFE) | Stainless Steel | Gold | Cap Free Hanging | 50 Ohms | Plug Male Pin | N Type | 6000 MHz | Beryllium Copper | |
 Radiall USA, Inc. | Polytetrafluoroethylene (PTFE) | Stainless Steel | Gold | Cap Free Hanging | 50 Ohms | Plug Male Pin | TNC | 6000 MHz | Beryllium Copper |
