842-028 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 28POS 0.100
| Part | Termination Rows | Material - Insulation | Contact Type | Card Thickness [Max] | Card Thickness [Min] | Mounting Type | Card Type | Contact Finish | Number of Positions | Color | Number of Positions/Bay/Row | Number of Rows | Pitch | Pitch | Contact Finish Thickness | Contact Finish Thickness | Gender | Termination | Operating Temperature [Max] | Operating Temperature [Min] | Read Out | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Contact Material | Termination Rows [custom] | Number of Rows [custom] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Non Specified - Single Edge | Gold | 28 | Green | 28 | 1 | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Female | Wire Wrap | 125 °C | -40 C | Single | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | Copper Alloy | |||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Non Specified - Single Edge | Gold | 28 | Green | 28 | 1 | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Female | Wire Wrap | 125 °C | -40 C | Single | 4-40 Flush Mount Threaded Insert Top Opening | Copper Alloy | |||||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | Non Specified - Single Edge | Gold | 28 | Green | 28 | 1 | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Female | Solder | 125 °C | -40 C | Single | Copper Alloy | ||||||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | Non Specified - Single Edge | Gold | 28 | Green | 28 | 1 | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Female | Solder | 125 °C | -40 C | Single | Flush Mount M3 Threaded Insert Top Opening | Copper Alloy | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Non Specified - Dual Edge | Gold | 28 | Green | 14 | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Female | Wire Wrap | 125 °C | -40 C | Dual | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | Copper Alloy | 2 | 2 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Board Edge Straddle Mount | Non Specified - Dual Edge | Gold | 28 | Green | 14 | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Female | Solder | 125 °C | -40 C | Dual | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Copper Alloy | 2 | 2 | Card Extender | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Non Specified - Single Edge | Gold | 28 | Green | 28 | 1 | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Female | Wire Wrap | 125 °C | -40 C | Single | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Copper Alloy | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Non Specified - Dual Edge | Gold | 28 | Green | 14 | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Female | Solder | 125 °C | -40 C | Dual | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | Copper Alloy | 2 | 2 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Non Specified - Dual Edge | Gold | 28 | Green | 14 | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Female | Solder Eyelet(s) | 125 °C | -40 C | Dual | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | Copper Alloy | 2 | 2 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Non Specified - Dual Edge | Gold | 28 | Green | 14 | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Female | Wire Wrap | 125 °C | -40 C | Dual | Flush Mount M3 Threaded Insert Top Opening | Copper Alloy | 2 | 2 |
