78SR1 Series
Manufacturer: Texas Instruments
Beta
⌘K
DC DC CONVERTER 10V
| Part | Mounting Type | Number of Outputs | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [z] | Operating Temperature [Max] | Operating Temperature [Min] | Voltage - Input (Max) [Max] | Applications | Features | Voltage - Output 1 | Type | Package / Case | Current - Output (Max) [Max] | Voltage - Input (Min) [Min] | Efficiency |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Texas Instruments | Through Hole | 1 | 0.31 " | 7.9 mm | 22.9 mm | 0.94 in | 0.9 " | 23.9 mm | 85 °C | -40 °C | 30 V | ITE (Commercial) | OTP SCP | 10 V | Non-Isolated PoL Module | 3-SIP Module | 1.5 A | 14.5 V | |
Texas Instruments | Through Hole | 1 | 0.31 " | 7.9 mm | 22.9 mm | 0.94 in | 0.9 " | 23.9 mm | 85 °C | -40 °C | 30 V | ITE (Commercial) | OTP SCP | 5.25 V | Non-Isolated PoL Module | 3-SIP Module | 1.5 A | 14.5 V | |
Texas Instruments | Through Hole | 1 | 0.31 " | 7.9 mm | 22.9 mm | 0.94 in | 0.9 " | 23.9 mm | 85 °C | -40 °C | 30 V | ITE (Commercial) | OTP SCP | 13.9 V | Non-Isolated PoL Module | 3-SIP Module | 1.5 A | 14.5 V | |
Texas Instruments | Through Hole | 1 | 0.31 " | 7.9 mm | 22.9 mm | 0.94 in | 0.9 " | 23.9 mm | 85 °C | -40 °C | 30 V | ITE (Commercial) | OTP SCP | 8 V | Non-Isolated PoL Module | 3-SIP Module | 1.5 A | 14.5 V | |
 Texas Instruments | Through Hole Right Angle | 1 | 0.9 " | 22.9 mm | 23.9 mm | 0.31 in | 0.94 in | 7.9 mm | 85 °C | -40 °C | 30 V | ITE (Commercial) | OTP SCP | 15 V | Non-Isolated PoL Module | 3-SIP Module | 1.5 A | 14.5 V | |
Texas Instruments | Through Hole Right Angle | 1 | 0.9 " | 22.9 mm | 23.9 mm | 0.31 in | 0.94 in | 7.9 mm | 85 °C | -40 °C | 30 V | ITE (Commercial) | OTP SCP | 7.15 V | Non-Isolated PoL Module | 3-SIP Module | 1.5 A | 14.5 V | |
Texas Instruments | Through Hole Right Angle | 1 | 0.9 " | 22.9 mm | 23.9 mm | 0.31 in | 0.94 in | 7.9 mm | 85 °C | -40 °C | 30 V | ITE (Commercial) | OTP SCP | 12 V | Non-Isolated PoL Module | 3-SIP Module | 1.5 A | 14.5 V | 90 % |
Texas Instruments | Through Hole | 1 | 0.31 " | 7.9 mm | 22.9 mm | 0.94 in | 0.9 " | 23.9 mm | 85 °C | -40 °C | 30 V | ITE (Commercial) | OTP SCP | 6 V | Non-Isolated PoL Module | 3-SIP Module | 1.5 A | 14.5 V | |
Texas Instruments | Through Hole | 1 | 0.31 " | 7.9 mm | 22.9 mm | 0.94 in | 0.9 " | 23.9 mm | 85 °C | -40 °C | 30 V | ITE (Commercial) | OTP SCP | 12 V | Non-Isolated PoL Module | 3-SIP Module | 1.5 A | 14.5 V | 90 % |
Texas Instruments | Through Hole | 1 | 85 °C | -40 °C | 30 V | ITE (Commercial) | OTP SCP | 6 V | Non-Isolated PoL Module | 3-SIP Module | 1.5 A | 14.5 V |
