Micro-One Wire-to-Board Header, Vertical, 2.00mm Pitch, Single Row, Glow-Wire Capable, Through Hole, 3 Circuits, Tin-Bismuth Plating, Black, with Potting Capability
Micro-One Wire-to-Board Header, Vertical, 2.00mm Pitch, Single Row, Glow-Wire Capable, Through Hole, 3 Circuits, Tin-Bismuth Plating, Black, with Potting Capability
Micro-One Wire-to-Board Header, Vertical, 2.00mm Pitch, Single Row, Glow-Wire Capable, Through Hole, 3 Circuits, Tin-Bismuth Plating, Black, with Potting Capability
| Part | Material Flammability Rating | Number of Rows | Contact Shape | Contact Finish Thickness - Mating [custom] | Contact Finish Thickness - Mating [custom] | Contact Finish - Post | Insulation Height | Insulation Height | Operating Temperature [Min] | Operating Temperature [Max] | Contact Material | Fastening Type | Contact Type | Number of Positions | Shrouding | Insulation Material | Pitch - Mating | Pitch - Mating | Features | Current Rating (Amps) | Mounting Type | Insulation Color | Number of Positions Loaded | Connector Type | Termination | Voltage Rating | Contact Length - Post [x] | Contact Length - Post [x] | Style |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Molex | UL94 V-0 | 1 | Square | 39.4 µin | 1 µm | Tin | 9.8 mm | 0.386 in | -40 C | 105 ░C | Brass | Push-Pull | Male Pin | 2 | Shrouded - 4 Wall | Liquid Crystal Polymer (LCP) | 0.079 " | 2 mm | Potting Wall | Varies by Wire Gauge | Through Hole | Black | All | Header | Solder | 250 VAC | 0.114 in | 2.9 mm | Board to Cable/Wire |
 Molex | UL94 V-0 | 1 | Square | 39.4 µin | 1 µm | Tin | 9.8 mm | 0.386 in | -40 C | 105 ░C | Brass | Push-Pull | Male Pin | 6 | Shrouded - 4 Wall | Liquid Crystal Polymer (LCP) | 0.079 " | 2 mm | Potting Wall | Varies by Wire Gauge | Through Hole | Black | All | Header | Solder | 250 VAC | 0.114 in | 2.9 mm | Board to Cable/Wire |
 Molex | UL94 V-0 | 1 | Square | 39.4 µin | 1 µm | Tin | 9.8 mm | 0.386 in | -40 C | 105 ░C | Brass | Push-Pull | Male Pin | 7 | Shrouded - 4 Wall | Liquid Crystal Polymer (LCP) | 0.079 " | 2 mm | Potting Wall | Varies by Wire Gauge | Through Hole | Black | All | Header | Solder | 250 VAC | 0.114 in | 2.9 mm | Board to Cable/Wire |
