857-043 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 43POS 0.156
| Part | Material - Insulation | Contact Finish Thickness | Contact Finish Thickness | Contact Material | Contact Finish | Color | Number of Positions | Card Thickness [Max] | Card Thickness [Min] | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Pitch | Pitch | Card Type | Mounting Type | Read Out | Contact Type | Gender | Termination Rows | Number of Positions/Bay/Row | Number of Rows | Termination | Operating Temperature [Max] | Operating Temperature [Min] | Number of Rows [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 0.25 Ám | 10 Áin | Copper Alloy | Gold | Black | 43 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | 3.96 mm | 0.156 in | Non Specified - Single Edge | Through Hole | Single | Semi Bellows | Female | 1 | 43 | 1 | Solder | 125 °C | -40 C | |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 0.25 Ám | 10 Áin | Copper Alloy | Gold | Black | 43 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | 3.96 mm | 0.156 in | Non Specified - Single Edge | Through Hole | Single | Semi Bellows | Female | 1 | 43 | 1 | Solder Eyelet(s) | 125 °C | -40 C | |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 0.25 Ám | 10 Áin | Copper Alloy | Gold | Black | 43 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | 3.96 mm | 0.156 in | Non Specified - Single Edge | Right Angle Through Hole | Single | Semi Bellows | Female | 1 | 43 | 1 | Solder | 125 °C | -40 C | |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 0.25 Ám | 10 Áin | Copper Alloy | Gold | Black | 43 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | 3.96 mm | 0.156 in | Non Specified - Single Edge | Through Hole | Single | Semi Bellows | Female | 1 | 43 | 1 | Solder | 125 °C | -40 C | |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Copper Alloy | Tin | Black | 86 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | 3.96 mm | 0.156 in | Non Specified - Dual Edge | Right Angle Through Hole | Dual | Semi Bellows | Female | 1 | 43 | Solder | 125 °C | -40 C | 2 | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Copper Alloy | Tin | Black | 43 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount M3 Threaded Insert Top Opening | 3.96 mm | 0.156 in | Non Specified - Single Edge | Through Hole | Single | Semi Bellows | Female | 1 | 43 | 1 | Wire Wrap | 125 °C | -40 C | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Copper Alloy | Tin | Black | 86 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | 3.96 mm | 0.156 in | Non Specified - Dual Edge | Right Angle Through Hole | Dual | Semi Bellows | Female | 1 | 43 | Solder | 125 °C | -40 C | 2 | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Copper Alloy | Tin | Black | 43 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | 3.96 mm | 0.156 in | Non Specified - Single Edge | Right Angle Through Hole | Single | Semi Bellows | Female | 1 | 43 | 1 | Solder | 125 °C | -40 C | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 0.25 Ám | 10 Áin | Copper Alloy | Gold | Black | 86 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | 3.96 mm | 0.156 in | Non Specified - Dual Edge | Through Hole | Dual | Semi Bellows | Female | 1 | 43 | Solder Eyelet(s) | 125 °C | -40 C | 2 | |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Copper Alloy | Tin | Black | 43 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | 3.96 mm | 0.156 in | Non Specified - Single Edge | Through Hole | Single | Semi Bellows | Female | 1 | 43 | 1 | Solder | 125 °C | -40 C |
