M80-552 Series

Catalog

7+7 POS. MALE DIL HORIZONTAL SMT CONN. NO JACKSCREWS ROHS COMPLIANT: YES

Part	Contact Finish Thickness - Post [custom]	Contact Finish Thickness - Post [custom]	Shrouding	Fastening Type	Connector Type	Insulation Material	Contact Finish - Mating	Insulation Color	Number of Positions	Contact Type	Contact Shape	Insulation Height	Insulation Height	Contact Finish - Post	Number of Positions Loaded	Current Rating (Amps)	Termination	Voltage Rating	Mounting Type	Contact Finish Thickness - Mating [custom]	Contact Finish Thickness - Mating [custom]	Style	Features	Operating Temperature [Min]	Operating Temperature [Max]	Material Flammability Rating	Pitch - Mating	Pitch - Mating	Row Spacing - Mating	Row Spacing - Mating	Contact Material	Number of Rows [custom]	Contact Finish Thickness - Post	Contact Finish Thickness - Post
Harwin Inc. M80-5521442	118.1 µin	3 µm	Shrouded - 4 Wall	Push-Pull	Header	Polyphenylene Sulfide (PPS) Glass Filled	Gold	Black	14	Male Pin	Circular	5.55 mm	0.218 in	Tin	All	2.2 A	Solder	800 V	Right Angle Surface Mount	29.5 µin	0.75 µm	Board to Board Cable	Keying Slot Mating Flange	-55 C	125 °C	UL94 V-0	0.079 "	2 mm	2 mm	0.079 in	Brass	2
Harwin Inc. M80-5523405			Shrouded - 4 Wall	Push-Pull	Header	Polyphenylene Sulfide (PPS) Glass Filled	Gold	Black	24	Male Pin	Circular	5.6 mm	0.22 in	Gold	All	2.2 A	Solder	800 VAC	Right Angle Surface Mount	29.5 µin	0.75 µm	Board to Board Cable	Keying Slot Mating Flange	-55 C	125 °C	UL94 V-0	0.079 "	2 mm	2 mm	0.079 in	Brass	2	29.5 µin	0.75 µm
Harwin Inc. M80-5522642	118.1 µin	3 µm	Shrouded - 4 Wall	Push-Pull	Header	Polyphenylene Sulfide (PPS) Glass Filled	Gold	Black	26	Male Pin	Circular	5.55 mm	0.218 in	Tin	All	2.2 A	Solder	800 V	Right Angle Surface Mount	29.5 µin	0.75 µm	Board to Board Cable	Keying Slot Mating Flange	-55 C	125 °C	UL94 V-0	0.079 "	2 mm	2 mm	0.079 in	Brass	2
Harwin Inc. M80-5521242	118.1 µin	3 µm	Shrouded - 4 Wall	Push-Pull	Header	Polyphenylene Sulfide (PPS) Glass Filled	Gold	Black	12	Male Pin	Circular	5.55 mm	0.218 in	Tin	All	2.2 A	Solder	800 V	Right Angle Surface Mount	29.5 µin	0.75 µm	Board to Board Cable	Keying Slot Mating Flange	-55 C	125 °C	UL94 V-0	0.079 "	2 mm	2 mm	0.079 in	Brass	2
