T110 Series

Manufacturer: KEMET

Catalog

TANTALUM CAPACITORS - SOLID LEADED 100VOLTS 0.47UF 10%

Part	Mounting Type	Package / Case	Manufacturer Size Code	Operating Temperature [Min]	Operating Temperature [Max]	Type	Voltage - Rated	Tolerance	Features	Capacitance	ESR (Equivalent Series Resistance)	Size / Dimension [diameter]	Size / Dimension [x]	Size / Dimension [diameter]	Size / Dimension [x]	Qualification	Grade	Size / Dimension [z]	Size / Dimension [z]
KEMET T110A474K100AT	Through Hole	Axial	A	-55 C	125 °C	Hermetically Sealed	100 V	10 %	General Purpose	0.47 µF	12 Ohm	0.135 "	0.286 in	3.43 mm	7.26 mm
KEMET T110A103K035AS	Through Hole	Axial	A	-55 C	125 °C	Hermetically Sealed	35 V	10 %	General Purpose	10000 pF		0.135 "	0.286 in	3.43 mm	7.26 mm
KEMET T110D686K020AS	Through Hole	Axial	D	-55 C	125 °C	Hermetically Sealed	20 V	10 %	General Purpose	68 µF	900 mOhm			0.351 in 8.92 mm	0.351 in 8.92 mm	MIL-PRF-39003/1	Military
KEMET T110D227M010AS7200	Through Hole	Axial	D	-55 C	125 °C	Hermetically Sealed	10 V	20 %	General Purpose	220 µF	600 mOhm	0.351 "		8.92 mm				19.96 mm	0.786 in
KEMET T110D277K006AT	Through Hole	Axial	D	-55 C	125 °C	Hermetically Sealed	6 VDC	10 %	General Purpose	270 µF	900 mOhm	0.351 "		8.92 mm				19.96 mm	0.786 in
KEMET T110A155K020AT	Through Hole	Axial	A	-55 C	125 °C	Hermetically Sealed	20 V	10 %	General Purpose	1500 nF	9 Ohm	0.135 "	0.286 in	3.43 mm	7.26 mm
KEMET T110A104M035AS01007200	Through Hole	Axial	A	-55 C	125 °C	Hermetically Sealed	35 V	20 %	General Purpose	100000 pF				0.125 in 3.18 mm				6.35 mm
KEMET T110A685J006AT	Through Hole	Axial	A	-55 C	125 °C	Hermetically Sealed	6 VDC	5 %	General Purpose	6.8 µF	8 Ohm	0.135 "	0.286 in	3.43 mm	7.26 mm
KEMET T110B566K006AS	Through Hole	Axial	B	-55 C	125 °C	Hermetically Sealed	6 VDC	10 %	General Purpose	56 µF	2000 mOhm	0.185 in		4.7 mm		MIL-PRF-39003/1	Military	12.04 mm	0.474 in
KEMET T110C107M010AS	Through Hole	Axial		-55 C	125 °C	Hermetically Sealed	10 V	20 %	General Purpose	100 µF	1 Ohm	0.289 in	0.686 "	7.34 mm	17.42 mm
