857-012 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 12POS 0.156
| Part | Termination Rows | Material - Insulation | Operating Temperature [Max] | Operating Temperature [Min] | Contact Material | Contact Type | Card Type | Color | Read Out | Pitch | Pitch | Number of Rows | Card Thickness [Max] | Card Thickness [Min] | Mounting Type | Contact Finish Thickness | Contact Finish Thickness | Termination | Gender | Number of Positions/Bay/Row | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Number of Positions | Contact Finish | Termination Rows [custom] | Number of Rows [custom] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | Copper Alloy | Semi Bellows | Non Specified - Single Edge | Black | Single | 3.96 mm | 0.156 in | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 0.25 Ám | 10 Áin | Wire Wrap | Female | 12 | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | 12 | Gold | |||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | Copper Alloy | Semi Bellows | Non Specified - Single Edge | Black | Single | 3.96 mm | 0.156 in | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Solder | Female | 12 | 12 | Tin | ||||||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | Copper Alloy | Semi Bellows | Non Specified - Dual Edge | Black | Dual | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Board Edge Straddle Mount | Solder | Female | 6 | 0.156 " | Flush Mount Top Opening Unthreaded | 3.96 mm | 12 | Tin | 2 | 2 | Card Extender | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | Copper Alloy | Semi Bellows | Non Specified - Dual Edge | Black | Dual | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 0.25 Ám | 10 Áin | Wire Wrap | Female | 6 | 4-40 Flush Mount Threaded Insert Top Opening | 12 | Gold | 2 | 2 | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | Copper Alloy | Semi Bellows | Non Specified - Dual Edge | Black | Dual | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Board Edge Straddle Mount | 0.25 Ám | 10 Áin | Solder | Female | 6 | Flush Mount M3 Threaded Insert Top Opening | 12 | Gold | 2 | 2 | Card Extender | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | Copper Alloy | Semi Bellows | Non Specified - Dual Edge | Black | Dual | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 0.25 Ám | 10 Áin | Solder | Female | 6 | 12 | Gold | 2 | 2 | ||||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | Copper Alloy | Semi Bellows | Non Specified - Dual Edge | Black | Single | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | Solder | Female | 6 | 4-40 Flush Mount Threaded Insert Top Opening | 12 | Tin | 2 | 2 | |||||||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | Copper Alloy | Semi Bellows | Non Specified - Single Edge | Black | Single | 3.96 mm | 0.156 in | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 0.25 Ám | 10 Áin | Wire Wrap | Female | 12 | Flush Mount M3 Threaded Insert Top Opening | 12 | Gold | |||||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | Copper Alloy | Semi Bellows | Non Specified - Single Edge | Black | Single | 3.96 mm | 0.156 in | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | Solder | Female | 12 | 12 | Tin | ||||||||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | Copper Alloy | Semi Bellows | Non Specified - Single Edge | Black | Single | 3.96 mm | 0.156 in | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | Solder | Female | 12 | 0.156 " | Flush Mount Top Opening Unthreaded | 3.96 mm | 12 | Tin |
