EEU-ED Series

Manufacturer: Panasonic Industrial Automation Sales

Catalog

CAP ALUM 220UF 20% 250V RADIAL

Part	Applications	Mounting Type	Tolerance	Capacitance	Package / Case	Voltage - Rated	Size / Dimension [diameter]	Size / Dimension [diameter]	Lead Spacing	Lead Spacing	Ripple Current @ Low Frequency	Operating Temperature [Min]	Operating Temperature [Max]	Ripple Current @ High Frequency	Lifetime @ Temp.	Polarization	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]
Panasonic Industrial Automation Sales EEU-ED2E221	General Purpose	Through Hole	20 %	220 µF	Radial Can	250 V	0.709 "	18 mm	7.5 mm	0.295 in	945 mA	-25 °C	105 ░C	2.1 A	10000 Hrs	Polar	1.575 in	40 mm
Panasonic Industrial Automation Sales EEU-ED2E820B	General Purpose	Through Hole	20 %	82 µF	Radial Can	250 V	0.63 in	16 mm	7.5 mm	0.295 in	480 mA	-25 °C	105 ░C	1.2 A	10000 Hrs	Polar	1.063 in	27 mm
Panasonic Industrial Automation Sales EEU-ED2G470	General Purpose	Through Hole	20 %	47 µF	Radial Can	400 V	0.63 in	16 mm	7.5 mm	0.295 in	336 mA	-25 °C	105 ░C	840 mA	10000 Hrs	Polar	0.984 "	25 mm
Panasonic Industrial Automation Sales EEU-ED2C151SB	General Purpose	Through Hole	20 %	150 µF	Radial Can	160 V	0.709 "	18 mm	7.5 mm	0.295 in	630 mA	-25 °C	105 ░C	1.4 A	10000 Hrs	Polar	0.866 in	22 mm
Panasonic Industrial Automation Sales EEU-ED2V470S	General Purpose	Through Hole	20 %	47 µF	Radial Can	350 V	0.709 "	18 mm	7.5 mm	0.295 in	320 mA	-25 °C	105 ░C	800 mA	10000 Hrs	Polar	0.787 "	20 mm
Panasonic Industrial Automation Sales EEU-ED2G100B	General Purpose	Through Hole	20 %	10 µF	Radial Can	400 V	0.394 in	10 mm	5 mm	0.197 in	120 mA	-25 °C	105 ░C	300 mA	8000 Hrs	Polar	0.866 in	22 mm
Panasonic Industrial Automation Sales EEU-ED2V680	General Purpose	Through Hole	20 %	68 µF	Radial Can	350 V	0.63 in	16 mm	7.5 mm	0.295 in	440 mA	-25 °C	105 ░C	1.1 A	10000 Hrs	Polar			31.5 mm	1.24 in
Panasonic Industrial Automation Sales EEU-ED2C151	General Purpose	Through Hole	20 %	150 µF	Radial Can	160 V	0.63 in	16 mm	7.5 mm	0.295 in	630 mA	-25 °C	105 ░C	1.4 A	10000 Hrs	Polar	0.984 "	25 mm
Panasonic Industrial Automation Sales EEU-ED2E101S	General Purpose	Through Hole	20 %	100 µF	Radial Can	250 V	0.709 "	18 mm	7.5 mm	0.295 in	675 mA	-25 °C	105 ░C	1.5 A	10000 Hrs	Polar	0.984 "	25 mm
Panasonic Industrial Automation Sales EEU-ED2E101SB	General Purpose	Through Hole	20 %	100 µF	Radial Can	250 V	0.709 "	18 mm	7.5 mm	0.295 in	675 mA	-25 °C	105 ░C	1.5 A	10000 Hrs	Polar	1.063 in	27 mm
