TSC-100 Series

Catalog

RELAY TIME DELAY 60SEC 1A 120V

Part	Relay Type	Timing Initiate Method	Function	Voltage - Supply [Min]	Voltage - Supply [Max]	Delay Time [Min]	Delay Time [Max]	Contact Rating @ Voltage	Mounting Type	Timing Adjustment Method	Termination Style
ATC-Diversified Electronics TSC-100-AFC-060	Solid State Relay	Input Voltage	On-Delay	12 VDC 24 VAC	240 VAC 240 VDC	0.6 Sec	60 Sec	1 A 120 VAC	Chassis Mount	Fixed	Quick Connect
ATC-Diversified Electronics TSC-100-ARC-010	Solid State Relay	Input Voltage	On-Delay	12 VDC 24 VAC	240 VAC 240 VDC	0.1 Sec	10 s	1 A 120 VAC	Chassis Mount	External Resistor	Quick Connect
