Nano-Fit Vertical Header, Through Hole, 2.50mm Pitch, Single Row, 4 Circuits, with Solder Clips, 0.76µm Gold (Au) Plating, Black, Glow-Wire Capable, Tray
Nano-Fit Vertical Header, Through Hole, 2.50mm Pitch, Single Row, 4 Circuits, with Solder Clips, 0.76µm Gold (Au) Plating, Black, Glow-Wire Capable, Tray
Nano-Fit Vertical Header, Through Hole, 2.50mm Pitch, Single Row, 4 Circuits, with Solder Clips, 0.76µm Gold (Au) Plating, Black, Glow-Wire Capable, Tray
| Part | Features | Contact Finish - Post | Applications | Connector Type | Insulation Height [z] | Insulation Height [z] | Insulation Color | Number of Positions Loaded | Contact Material | Mounting Type | Insulation Material | Contact Finish - Mating | Number of Rows | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Contact Shape | Mated Stacking Heights | Voltage Rating | Pitch - Mating | Pitch - Mating | Number of Positions | Shrouding | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Operating Temperature [Min] | Operating Temperature [Max] | Style | Fastening Type | Contact Length - Post | Contact Length - Post [x] | Contact Type | Termination | Insulation Height | Insulation Height | Current Rating (Amps) | Material Flammability Rating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Molex | Board Guide Board Lock | Tin | Automotive General Purpose Industrial Medical Military Telecommunications | Header | 0.356 in | 9.05 mm | Black | All | Brass | Through Hole | Liquid Crystal Polymer (LCP) | Gold | 1 | 30 Áin | 0.76 Ám | Square | 21.3 mm | 250 VDC | 2.5 mm | 0.098 in | 4 | Shrouded - 4 Wall | 1.5 µm | 59 µin | -40 °C | 105 ░C | Board to Cable/Wire | Latch Holder | 3.2 mm | 0.126 in | Male Pin | Solder | ||||
 Molex | Board Guide Board Lock | Tin | Automotive General Purpose Industrial Medical Military Telecommunications | Header | 0.356 in | 9.05 mm | Black | All | Brass | Through Hole | Liquid Crystal Polymer (LCP) | Gold | 1 | 15 µin | 0.38 µm | Square | 21.3 mm | 250 VDC | 2.5 mm | 0.098 in | 2 | Shrouded - 4 Wall | 1.5 µm | 59 µin | -40 °C | 105 ░C | Board to Cable/Wire | Latch Holder | 3.2 mm | 0.126 in | Male Pin | Solder | ||||
 Molex | Board Guide Board Lock | Tin | Automotive General Purpose Industrial Medical Military Telecommunications | Header | 0.356 in | 9.05 mm | Black | All | Brass | Through Hole | Liquid Crystal Polymer (LCP) | 1 | 59 Áin | 1.5 Ám | Square | 21.3 mm | 250 VDC | 2.5 mm | 0.098 in | Shrouded - 4 Wall | 1.5 µm | 59 µin | -40 °C | 105 ░C | Board to Cable/Wire | Latch Holder | 3.2 mm | 0.126 in | Male Pin | Solder | ||||||
 Molex | Board Guide Board Lock | Tin | Automotive General Purpose Industrial Medical Military Telecommunications | Header | 0.356 in | 9.05 mm | Natural | All | Brass | Through Hole | Liquid Crystal Polymer (LCP) | Gold | 1 | 30 Áin | 0.76 Ám | Square | 21.3 mm | 250 VDC | 2.5 mm | 0.098 in | 4 | Shrouded - 4 Wall | 1.5 µm | 59 µin | -40 °C | 105 ░C | Board to Cable/Wire | Latch Holder | 3.2 mm | 0.126 in | Male Pin | Solder | ||||
 Molex | Board Guide Board Lock | Tin | Automotive General Purpose Industrial Medical Military Telecommunications | Header | 0.356 in | 9.05 mm | Natural | All | Brass | Through Hole | Liquid Crystal Polymer (LCP) | Gold | 1 | 15 µin | 0.38 µm | Square | 21.3 mm | 250 VDC | 2.5 mm | 0.098 in | 7 | Shrouded - 4 Wall | 1.5 µm | 59 µin | -40 °C | 105 ░C | Board to Cable/Wire | Latch Holder | 3.2 mm | 0.126 in | Male Pin | Solder | ||||
 Molex | Board Guide Board Lock | Tin | Automotive General Purpose Industrial Medical Military Telecommunications | Header | 0.356 in | 9.05 mm | Natural | All | Brass | Through Hole | Liquid Crystal Polymer (LCP) | 1 | 59 Áin | 1.5 Ám | Square | 21.3 mm | 250 VDC | 2.5 mm | 0.098 in | 2 | Shrouded - 4 Wall | 1.5 µm | 59 µin | -40 °C | 105 ░C | Board to Cable/Wire | Latch Holder | 3.2 mm | 0.126 in | Male Pin | Solder | |||||
 Molex | Board Guide Board Lock | Tin | Automotive General Purpose Industrial Medical Military Telecommunications | Header | 0.356 in | 9.05 mm | Natural | All | Brass | Through Hole | Liquid Crystal Polymer (LCP) | Gold | 1 | 30 Áin | 0.76 Ám | Square | 21.3 mm | 250 VDC | 2.5 mm | 0.098 in | Shrouded - 4 Wall | 1.5 µm | 59 µin | -40 °C | 105 ░C | Board to Cable/Wire | Latch Holder | 3.2 mm | 0.126 in | Male Pin | Solder | |||||
 Molex | Board Guide Board Lock | Tin | Automotive General Purpose Industrial Medical Military Telecommunications | Header | 0.356 in | 9.05 mm | Natural | All | Brass | Through Hole | Liquid Crystal Polymer (LCP) | 1 | 59 Áin | 1.5 Ám | Square | 21.3 mm | 250 VDC | 2.5 mm | 0.098 in | 7 | Shrouded - 4 Wall | 1.5 µm | 59 µin | -40 °C | 105 ░C | Board to Cable/Wire | Latch Holder | 3.2 mm | 0.126 in | Male Pin | Solder | |||||
Molex | ||||||||||||||||||||||||||||||||||||
Molex | Tin | Header | Black | All | Brass | Through Hole | Liquid Crystal Polymer (LCP) | Gold | 1 | 30 Áin | 0.76 Ám | Square | 250 VAC | 2.5 mm | 0.098 in | Shrouded - 4 Wall | 1.5 µm | 59 µin | -40 °C | 115 °C | Board to Cable/Wire | Latch Holder | 3.2 mm | 0.126 in | Male Pin | Solder | 10.52 mm | 0.414 in | Varies by Wire Gauge | UL94 V-0 |
