MTLW-129 Series
Manufacturer: Samtec Inc.
Catalog
CONN HEADER VERT 58POS 2.54MM
| Part | Contact Shape | Insulation Material | Contact Finish - Mating | Termination | Operating Temperature [Min] | Operating Temperature [Max] | Material Flammability Rating | Contact Material | Contact Type | Style | Contact Finish - Post | Mounting Type | Connector Type | Pitch - Mating | Pitch - Mating | Fastening Type | Insulation Color | Number of Rows | Shrouding | Number of Positions | Overall Contact Length | Overall Contact Length | Row Spacing - Mating [x] | Row Spacing - Mating [x] | Insulation Height [z] | Insulation Height [z] | Contact Length - Mating | Contact Length - Mating | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Contact Length - Post | Contact Length - Post | Number of Positions Loaded | Current Rating (Amps) | Contact Finish Thickness - Post | Contact Finish Thickness - Post |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Samtec Inc. | ||||||||||||||||||||||||||||||||||||
 Samtec Inc. | Square | Liquid Crystal Polymer (LCP) | Gold | Solder | -55 °C | 125 °C | UL94 V-0 | Phosphor Bronze | Male Pin | Board to Board Cable | Tin | Through Hole | Header | 0.1 in | 2.54 mm | Push-Pull | Black | 2 | Unshrouded | 58 | ||||||||||||||||
 Samtec Inc. | Square | Liquid Crystal Polymer (LCP) | Gold | Solder | -55 °C | 125 °C | UL94 V-0 | Phosphor Bronze | Male Pin | Board to Board Cable | Gold | Through Hole | Header | 0.1 in | 2.54 mm | Push-Pull | Black | 2 | Unshrouded | 58 | 0.48 in | 12.19 mm | 2.54 mm | 0.1 in | 0.06 in | 1.52 mm | 0.33 in | 8.38 mm | 10 çin | 0.25 çm | 0.09 " | 2.29 mm | All | 5.2 A | 3 µin | 0.076 µm |
Samtec Inc. |
