EBQA Series
Manufacturer: Adam Tech
Beta
⌘K
EURO BLOCK 2P
| Part | Insulation Height | Insulation Height | Material Flammability Rating | Contact Tail Length | Contact Tail Length | Contact Material | Color | Voltage - UL | Header Orientation | Mounting Type | Contact Mating Finish | Operating Temperature [Min] | Operating Temperature [Max] | Pitch | Pitch | Number of Levels | Positions Per Level | Type | Number of Positions | Termination Style |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Adam Tech | 0.335 " | 8.51 mm | UL94 V-0 | 0.157 in | 4 mm | Brass | Green | 300 V | 90° Right Angle | Through Hole | Tin | -40 C | 105 ░C | 5.08 mm | 0.2 in | 1 | 2 | Header Male Pins Shrouded (2 Side) | 2 | Solder |
 Adam Tech | 0.335 " | 8.51 mm | UL94 V-0 | 0.157 in | 4 mm | Brass | Green | 300 V | 90° Right Angle | Through Hole | Tin | -40 C | 105 ░C | 5.08 mm | 0.2 in | 1 | 3 | Header Male Pins Shrouded (2 Side) | Solder | |
 Adam Tech | 0.335 " | 8.51 mm | UL94 V-0 | 0.157 in | 4 mm | Brass | Green | 300 V | 90° Right Angle | Through Hole | Tin | -40 C | 105 ░C | 5.08 mm | 0.2 in | 1 | 3 | Header Male Pins Shrouded (4 Side) | Solder | |
 Adam Tech | 0.335 " | 8.51 mm | UL94 V-0 | 0.157 in | 4 mm | Brass | Green | 300 V | 90° Right Angle | Through Hole | Tin | -40 C | 105 ░C | 5 mm | 0.197 in | 1 | 4 | Header Male Pins Shrouded (2 Side) | 4 | Solder |
 Adam Tech | 0.335 " | 8.51 mm | UL94 V-0 | 0.157 in | 4 mm | Brass | Green | 300 V | 90° Right Angle | Through Hole | Tin | -40 C | 105 ░C | 5 mm | 0.197 in | 1 | 5 | Header Male Pins Shrouded (4 Side) | 5 | Solder |
 Adam Tech | 0.335 " | 8.51 mm | UL94 V-0 | 0.157 in | 4 mm | Brass | Green | 300 V | 90° Right Angle | Through Hole | Tin | -40 C | 105 ░C | 5 mm | 0.197 in | 1 | 3 | Header Male Pins Shrouded (4 Side) | Solder | |
 Adam Tech | 0.335 " | 8.51 mm | UL94 V-0 | 0.157 in | 4 mm | Brass | Green | 300 V | 90° Right Angle | Through Hole | Tin | -40 C | 105 ░C | 5.08 mm | 0.2 in | 1 | 4 | Header Male Pins Shrouded (4 Side) | 4 | Solder |
Adam Tech | 0.335 " | 8.51 mm | UL94 V-0 | 0.157 in | 4 mm | Brass | Green | 300 V | 90° Right Angle | Through Hole | Tin | -40 C | 105 ░C | 5 mm | 0.197 in | 1 | 5 | Header Male Pins Shrouded (2 Side) | 5 | Solder |
 Adam Tech | 0.335 " | 8.51 mm | UL94 V-0 | 0.157 in | 4 mm | Brass | Green | 300 V | 90° Right Angle | Through Hole | Tin | -40 C | 105 ░C | 5.08 mm | 0.2 in | 1 | 4 | Header Male Pins Shrouded (2 Side) | 4 | Solder |
 Adam Tech | 0.335 " | 8.51 mm | UL94 V-0 | 0.157 in | 4 mm | Brass | Green | 300 V | 90° Right Angle | Through Hole | Tin | -40 C | 105 ░C | 5.08 mm | 0.2 in | 1 | 2 | Header Male Pins Shrouded (4 Side) | 2 | Solder |
