Mini-Fit Max Vertical Header, Single Row, Through Hole, 5 Circuits, Tin (Sn) Plating, Black, Glow-Wire Capable
Mini-Fit Max Vertical Header, Single Row, Through Hole, 5 Circuits, Tin (Sn) Plating, Black, Glow-Wire Capable
Mini-Fit Max Vertical Header, Single Row, Through Hole, 5 Circuits, Tin (Sn) Plating, Black, Glow-Wire Capable
| Part | Contact Material | Mounting Type | Number of Rows | Contact Shape | Number of Positions | Style | Contact Type | Connector Type | Insulation Material | Features | Current Rating (Amps) | Pitch - Mating | Pitch - Mating | Insulation Color | Number of Positions Loaded | Fastening Type | Voltage Rating | Shrouding | Termination | Operating Temperature [Min] | Operating Temperature [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Molex | Copper Alloy | Through Hole | 1 | Square | 6 | Board to Cable/Wire | Male Pin | Header | Liquid Crystal Polymer (LCP) | Board Guide | Varies by Wire Gauge | 4.2 mm | 0.165 in | Black | All | Locking Ramp | 600 VAC | Shrouded - 4 Wall | Solder | -40 °C | 105 ░C |
