621-M25 Series
Manufacturer: EDAC Inc.
Beta
⌘K
621M SERIES RIGHT ANGLE D-SUB PL
| Part | Dielectric Material | Operating Temperature [Min] | Operating Temperature [Max] | Color | Contact Material | Flange Feature | Flange Feature | Connector Type | Shell Size, Connector Layout | Shell Size, Connector Layout [x] | Backset Spacing | Backset Spacing | Number of Positions | Contact Finish | Contact Type | Mounting Type | Number of Rows [custom] | Connector Style | Material Flammability Rating | Features | Contact Finish Thickness | Contact Finish Thickness | Shell Material, Finish | Current Rating (Amps) | Termination | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | Green | Copper Alloy | Housing/Shell | 4-40 | Plug Male Pins | B DB | 3 | 7.2 mm | 0.283 in | 25 | Gold | Signal | Board Edge Right Angle Through Hole | 2 | D-Sub | UL94 V-0 | Board Lock Grounding Indents Mounting Brackets Shielded | 0.38 µm | 15 µin | Nickel Plated Steel | 5 A | Solder | |
 EDAC Inc. | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | White | Copper Alloy | Housing/Shell | 4-40 | Plug Male Pins | B DB | 3 | 7.2 mm | 0.283 in | 25 | Gold | Signal | Board Edge Right Angle Through Hole | 2 | D-Sub | UL94 V-0 | Board Lock Mounting Brackets Shielded | 0.76 Ám | 30 Áin | Nickel Plated Steel | 5 A | Solder | |
 EDAC Inc. | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | Black | Copper Alloy | 4-40 | Plug Male Pins | B DB | 3 | 7.2 mm | 0.283 in | 25 | Gold | Signal | Board Edge Right Angle Through Hole | 2 | D-Sub | UL94 V-0 | Board Lock Grounding Indents Mounting Brackets Shielded | 5 A | Solder | Flash | ||||
 EDAC Inc. | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | Green | Copper Alloy | 4-40 | Plug Male Pins | B DB | 3 | 7.2 mm | 0.283 in | 25 | Gold | Signal | Board Edge Right Angle Through Hole | 2 | D-Sub | UL94 V-0 | Board Lock Grounding Indents Mounting Brackets Shielded | 0.76 Ám | 30 Áin | Nickel Plated Steel | 5 A | Solder | ||
 EDAC Inc. | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | White | Copper Alloy | Housing/Shell | 4-40 | Plug Male Pins | B DB | 3 | 7.2 mm | 0.283 in | 25 | Gold | Signal | Board Edge Right Angle Through Hole | 2 | D-Sub | UL94 V-0 | Board Lock Mounting Brackets Shielded | 5 A | Solder | Flash | |||
 EDAC Inc. | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | Blue | Copper Alloy | Housing/Shell (Unthreaded) | Plug Male Pins | B DB | 3 | 7.2 mm | 0.283 in | 25 | Gold | Signal | Board Edge Right Angle Through Hole | 2 | D-Sub | UL94 V-0 | Grounding Indents Shielded | 0.38 µm | 15 µin | Nickel Plated Steel | 5 A | Solder | ||
 EDAC Inc. | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | Blue | Copper Alloy | Housing/Shell | 4-40 | Plug Male Pins | B DB | 3 | 7.2 mm | 0.283 in | 25 | Gold | Signal | Board Edge Right Angle Through Hole | 2 | D-Sub | UL94 V-0 | Board Lock Mounting Brackets Shielded | 0.38 µm | 15 µin | Nickel Plated Steel | 5 A | Solder | |
 EDAC Inc. | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | Blue | Copper Alloy | Housing/Shell | 4-40 | Plug Male Pins | B DB | 3 | 7.2 mm | 0.283 in | 25 | Gold | Signal | Board Edge Right Angle Through Hole | 2 | D-Sub | UL94 V-0 | Grounding Indents Shielded | 0.38 µm | 15 µin | Nickel Plated Steel | 5 A | Solder | |
 EDAC Inc. | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | Blue | Copper Alloy | Housing/Shell | 4-40 | Plug Male Pins | B DB | 3 | 7.2 mm | 0.283 in | 25 | Gold | Signal | Board Edge Right Angle Through Hole | 2 | D-Sub | UL94 V-0 | Board Lock Grounding Indents Mounting Brackets Shielded | 0.76 Ám | 30 Áin | 5 A | Solder | ||
 EDAC Inc. | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | Black | Copper Alloy | Housing/Shell | 4-40 | Plug Male Pins | B DB | 3 | 7.2 mm | 0.283 in | 25 | Gold | Signal | Board Edge Right Angle Through Hole | 2 | D-Sub | UL94 V-0 | Board Lock Grounding Indents Mounting Brackets Shielded | 0.76 Ám | 30 Áin | Nickel Plated Steel | 5 A | Solder |
