S5B-PH-K Series
Manufacturer: JST Sales America Inc.
Beta
⌘K
CONN HEADER R/A 5POS 2MM
| Part | Insulation Height | Insulation Height | Number of Rows | Connector Type | Contact Shape | Contact Material | Fastening Type | Contact Length - Mating | Contact Length - Mating | Voltage Rating | Material Flammability Rating | Insulation Material | Operating Temperature [Max] | Operating Temperature [Min] | Current Rating (Amps) | Style | Number of Positions Loaded | Insulation Color | Mounting Type | Termination | Contact Length - Post [x] | Contact Length - Post | Number of Positions | Shrouding | Contact Finish - Post | Pitch - Mating | Pitch - Mating | Contact Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 JST Sales America Inc. | 4.8 mm | 0.189 in | 1 | Header | Square | Brass | Detent Lock | 0.13 in | 3.3 mm | 100 V | UL94 V-0 | Nylon 6/6 Polyamide (PA66) | 85 °C | -25 °C | 2 A | Board to Cable/Wire | All | Natural | Right Angle Through Hole | Press-Fit Solder | 0.134 " | 3.4 mm | 5 | Shrouded - 4 Wall | Tin | 0.079 " | 2 mm | Male Pin |
 JST Sales America Inc. | 4.8 mm | 0.189 in | 1 | Header | Square | Copper Alloy | Detent Lock | 100 V | UL94 V-0 | Nylon 6/6 Polyamide (PA66) | 85 °C | -25 °C | 2 A | Board to Cable/Wire | All | Gray | Right Angle Through Hole | Press-Fit Solder | 0.134 " | 3.4 mm | 5 | Shrouded - 4 Wall | Tin | 0.079 " | 2 mm | Male Pin |
