74VCX86 Series

Catalog

LOW VOLTAGE QUAD 2-INPUT EXCLUSIVE-OR GATE WITH 3.6V TOLERANT INPUTS AND OUTPUTS

Part	Voltage - Supply [Min]	Voltage - Supply [Max]	Current - Quiescent (Max) [Max]	Mounting Type	Current - Output High, Low	Logic Type	Max Propagation Delay @ V, Max CL	Supplier Device Package	Number of Inputs	Input Logic Level - High [Max]	Input Logic Level - High [Min]	Package / Case	Input Logic Level - Low [Max]	Input Logic Level - Low [Min]	Operating Temperature [Max]	Operating Temperature [Min]	Number of Circuits	Package / Case [x]	Package / Case [y]
ON Semiconductor 74VCX86MTC
ON Semiconductor 74VCX86BQX	1.2 V	3.6 V	20 µA	Surface Mount	24 mA	XOR (Exclusive OR)	3 ns	14-DQFN (3x2.5)	2	2 V	1.6 V	14-VFQFN Exposed Pad	0.8 V	0.7 V	85 °C	-40 °C	4
ON Semiconductor 74VCX86M	1.2 V	3.6 V	20 µA	Surface Mount	24 mA	XOR (Exclusive OR)	3 ns		2	2 V	1.6 V	14-SOIC	0.8 V	0.7 V	85 °C	-40 °C	4	0.154 in	3.9 mm
ON Semiconductor 74VCX86M	1.2 V	3.6 V	20 µA	Surface Mount	24 mA	XOR (Exclusive OR)	3 ns		2	2 V	1.6 V	14-SOIC	0.8 V	0.7 V	85 °C	-40 °C	4	0.154 in	3.9 mm
ON Semiconductor 74VCX86BQX	1.2 V	3.6 V	20 µA	Surface Mount	24 mA	XOR (Exclusive OR)	3 ns	14-DQFN (3x2.5)	2	2 V	1.6 V	14-VFQFN Exposed Pad	0.8 V	0.7 V	85 °C	-40 °C	4
ON Semiconductor 74VCX86MX	1.2 V	3.6 V	20 µA	Surface Mount	24 mA	XOR (Exclusive OR)	3 ns		2	2 V	1.6 V	14-SOIC	0.8 V	0.7 V	85 °C	-40 °C	4	0.154 in	3.9 mm
