895-138 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FML 138POS 0.100
| Part | Termination Rows [custom] | Material - Insulation | Color | Termination | Card Type | Number of Positions [custom] | Mounting Type | Gender | Operating Temperature [Max] | Operating Temperature [Min] | Number of Positions/Bay/Row [custom] | Contact Finish | Contact Finish Thickness | Contact Finish Thickness | Features | Pitch | Pitch | Contact Material | Flange Feature | Contact Type | Number of Rows [custom] | Card Thickness [Max] | Card Thickness [Min] | Read Out | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Black | Solder | Non Specified - Dual Edge | 138 | Board Edge Straddle Mount | Female | 125 °C | -40 C | 69 | Gold | 0.25 Ám | 10 Áin | Card Extender | 0.1 " | 2.54 mm | Copper Alloy | M3 Threaded Insert Top Mount Opening | Cantilever | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | ||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Black | Solder | Non Specified - Dual Edge | 138 | Right Angle Through Hole | Female | 125 °C | -40 C | 69 | Gold | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Copper Alloy | Floating Bobbin Top Mount Opening | Cantilever | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | 0.116 " | 2.95 mm | |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Black | Solder | Non Specified - Dual Edge | 138 | Through Hole | Female | 125 °C | -40 C | 69 | Gold | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Copper Alloy | Side Mount Opening Unthreaded | Cantilever | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | 0.128 " | 3.25 mm | |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Black | Solder Eyelet(s) | Non Specified - Dual Edge | 138 | Through Hole | Female | 125 °C | -40 C | 69 | Gold | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Copper Alloy | Floating Bobbin Top Mount Opening | Cantilever | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | 0.116 " | 2.95 mm | |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Black | Solder | Non Specified - Dual Edge | 138 | Through Hole | Female | 125 °C | -40 C | 69 | Gold | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Copper Alloy | Cantilever | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | ||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Black | Solder | Non Specified - Dual Edge | 138 | Board Edge Straddle Mount | Female | 125 °C | -40 C | 69 | Gold | 0.25 Ám | 10 Áin | Card Extender | 0.1 " | 2.54 mm | Copper Alloy | M3 Threaded Insert Top Mount Opening | Cantilever | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | ||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Black | Solder | Non Specified - Dual Edge | 138 | Board Edge Straddle Mount | Female | 125 °C | -40 C | 69 | Gold | 0.25 Ám | 10 Áin | Card Extender | 0.1 " | 2.54 mm | Copper Alloy | Floating Bobbin Flush Mount | Cantilever | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | 0.116 " | 2.95 mm |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Black | Solder | Non Specified - Dual Edge | 138 | Board Edge Straddle Mount | Female | 125 °C | -40 C | 69 | Gold | 0.25 Ám | 10 Áin | Card Extender | 0.1 " | 2.54 mm | Copper Alloy | 4-40 Threaded Insert Top Mount Opening | Cantilever | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | ||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Black | Solder | Non Specified - Dual Edge | 138 | Board Edge Straddle Mount | Female | 125 °C | -40 C | 69 | Gold | 0.25 Ám | 10 Áin | Card Extender | 0.1 " | 2.54 mm | Copper Alloy | Cantilever | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | 0.128 " | 3.25 mm | |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Black | Solder | Non Specified - Dual Edge | 138 | Through Hole | Female | 125 °C | -40 C | 69 | Gold | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Copper Alloy | 4-40 Threaded Insert Top Mount Opening | Cantilever | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual |
