SRP1205 Series
Manufacturer: Bourns Inc.
Beta
⌘K
FIXED IND 2.5UH 11.5A 3.4MOHM SM
| Part | DC Resistance (DCR) | Frequency - Self Resonant | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Inductance | Shielding | Current Rating (Amps) | Tolerance | Material - Core | Type | Operating Temperature [Min] | Operating Temperature [Max] | Mounting Type | Package / Case | Inductance Frequency - Test | Height - Seated (Max) [Max] [z] | Height - Seated (Max) [Max] [z] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Bourns Inc. | 3.4 mOhm | 40 MHz | 12.5 mm | 0.492 " | 12.5 mm | 0.492 " | 2.5 µH | Shielded | 11.5 A | 25 % | Ferrite | Drum Core Wirewound | -55 C | 150 °C | Surface Mount | Nonstandard | 100 kHz | 5.6 mm | 0.22 in |
