A50 Series
Manufacturer: KEMET
Beta
⌘K
FILM CAPACITORS 250VDC 2.2 UF 105C 5% AEC-Q200
| Part | Size / Dimension [x] | Size / Dimension [diameter] | Size / Dimension [diameter] | Size / Dimension [x] | Voltage Rating - AC | Voltage Rating - DC | Voltage Rating - DC | Ratings | Dielectric Material | Applications | Tolerance | Operating Temperature [Min] | Operating Temperature [Max] | Mounting Type | Capacitance | Termination | Package / Case | Size / Dimension | Size / Dimension [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 KEMET | |||||||||||||||||||
 KEMET | 14 mm | 0.295 in | 7.5 mm | 0.551 in | 250 V | 1 kV | 1 kVDC | AEC-Q200 | Metallized Polyester Polyethylene Terephthalate (PET) | Automotive | 10 % | -55 C | 105 ░C | Through Hole | 0.0047 µF | PC Pins | Axial | ||
 KEMET | 0.472 " | 30 V | 50 VDC | AEC-Q200 | Metallized Polyester Polyethylene Terephthalate (PET) | Automotive | 20 % | -55 C | 105 ░C | Through Hole | 10 µF | PC Pins | Axial | 12 mm 20.5 mm | 0.807 " | ||||
 KEMET | 20.5 mm | 0.236 in | 6 mm | 0.807 " | 200 V | 400 V | AEC-Q200 | Metallized Polyester Polyethylene Terephthalate (PET) | Automotive | 10 % | -55 C | 105 ░C | Through Hole | 0.15 ÁF | PC Pins | Axial | |||
 KEMET | 33 mm | 0.433 " | 11 mm | 1.299 in | 160 V | 250 V | AEC-Q200 | Metallized Polyester Polyethylene Terephthalate (PET) | Automotive | 10 % | -55 C | 105 ░C | Through Hole | 2.2 µF | PC Pins | Axial | |||
 KEMET | 14 mm | 0.217 in | 5.5 mm | 0.551 in | 160 V | 250 V | AEC-Q200 | Metallized Polyester Polyethylene Terephthalate (PET) | Automotive | 5 % | -55 C | 105 ░C | Through Hole | 0.15 ÁF | PC Pins | Axial | |||
KEMET | 14 mm | 0.236 in | 6 mm | 0.551 in | 63 V | 100 V | AEC-Q200 | Metallized Polyester Polyethylene Terephthalate (PET) | Automotive | 10 % | -55 C | 105 ░C | Through Hole | 0.33 µF | PC Pins | Axial | |||
 KEMET | 28 mm | 0.335 in | 8.5 mm | 1.102 " | 160 V | 250 V | AEC-Q200 | Metallized Polyester Polyethylene Terephthalate (PET) | Automotive | 20 % | -55 C | 105 ░C | Through Hole | 1 µF | PC Pins | Axial | |||
KEMET | 11 mm | 0.256 in | 6.5 mm | 0.433 in | 30 V | 50 VDC | AEC-Q200 | Metallized Polyester Polyethylene Terephthalate (PET) | Automotive | 20 % | -55 C | 105 ░C | Through Hole | 1 µF | PC Pins | Axial | |||
KEMET | 28 mm | 0.276 in | 7 mm | 1.102 " | 220 V | AEC-Q200 | Metallized Polyester Polyethylene Terephthalate (PET) | Automotive | 10 % | -55 C | 105 ░C | Through Hole | 100000 pF | PC Pins | Axial |
