424-035 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 35POS 0.200
| Part | Material - Insulation | Termination Rows [custom] | Card Type | Number of Rows [custom] | Contact Finish Thickness | Contact Finish Thickness | Contact Finish | Contact Material | Operating Temperature [Min] | Operating Temperature [Max] | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Card Thickness | Card Thickness | Number of Positions | Color | Gender | Termination | Mounting Type | Pitch | Pitch |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Non Specified - Dual Edge | 2 | 0.25 Ám | 10 Áin | Gold | Copper Alloy | -65 ░C | 125 °C | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 2.36 mm | 0.093 " | 35 | Green | Female | Solder | Panel Mount Through Hole | 5.08 mm | 0.2 in |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Non Specified - Dual Edge | 2 | 0.25 Ám | 10 Áin | Gold | Copper Alloy | -65 ░C | 125 °C | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 2.36 mm | 0.093 " | 35 | Green | Female | Solder | Panel Mount Through Hole | 5.08 mm | 0.2 in |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Non Specified - Dual Edge | 2 | 0.25 Ám | 10 Áin | Gold | Copper Alloy | -65 ░C | 125 °C | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 2.36 mm | 0.093 " | 35 | Green | Female | Solder Eyelet(s) | Panel Mount Through Hole | 5.08 mm | 0.2 in |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Non Specified - Dual Edge | 2 | 0.25 Ám | 10 Áin | Gold | Copper Alloy | -65 ░C | 125 °C | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 2.36 mm | 0.093 " | 35 | Green | Female | Solder | Panel Mount Through Hole | 5.08 mm | 0.2 in |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Non Specified - Dual Edge | 2 | 0.25 Ám | 10 Áin | Gold | Copper Alloy | -65 ░C | 125 °C | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 1.57 mm | 0.062 in | 35 | Green | Female | Solder | Panel Mount Through Hole | 5.08 mm | 0.2 in |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Non Specified - Dual Edge | 2 | 0.25 Ám | 10 Áin | Gold | Copper Alloy | -65 ░C | 125 °C | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 2.36 mm | 0.093 " | 35 | Green | Female | Wire Wrap | Panel Mount Through Hole | 5.08 mm | 0.2 in |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Non Specified - Dual Edge | 2 | 0.25 Ám | 10 Áin | Gold | Copper Alloy | -65 ░C | 125 °C | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 1.57 mm | 0.062 in | 35 | Green | Female | Solder | Panel Mount Through Hole | 5.08 mm | 0.2 in |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Non Specified - Dual Edge | 2 | 0.25 Ám | 10 Áin | Gold | Copper Alloy | -65 ░C | 125 °C | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 1.57 mm | 0.062 in | 35 | Green | Female | Solder | Panel Mount Through Hole | 5.08 mm | 0.2 in |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Non Specified - Dual Edge | 2 | 0.25 Ám | 10 Áin | Gold | Copper Alloy | -65 ░C | 125 °C | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 2.36 mm | 0.093 " | 35 | Green | Female | Solder | Panel Mount Through Hole | 5.08 mm | 0.2 in |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Non Specified - Dual Edge | 2 | 0.25 Ám | 10 Áin | Gold | Copper Alloy | -65 ░C | 125 °C | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 1.57 mm | 0.062 in | 35 | Green | Female | Solder | Panel Mount Through Hole | 5.08 mm | 0.2 in |
