NEB-300 Series

Manufacturer: CUI Inc.

Catalog

DC DC CONVERTER 12V 300W

Part	Efficiency	Current - Output (Max) [Max]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Type	Features	Operating Temperature [Max]	Operating Temperature [Min]	Mounting Type	Number of Outputs	Control Features	Voltage - Input (Min) [Min]	Applications	Voltage - Isolation	Power (Watts)	Package / Case	Voltage - Output 1	Voltage - Input (Max) [Max]
CUI Inc. NEB-300DWA-AN	95.2 %	25 A	10.2 mm	0.4 "	58.4 mm	0.89 in	2.3 in	22.7 mm	Intermediate Bus Converter Digital	OCP OTP OVP Remote On/Off UVLO	125 °C	-40 C	Through Hole	1	Active Low Enable	40 V	ITE (Commercial)	2250 VDC	300 W	15-DIP Module 1/8 Brick	12 V	60 V
CUI Inc. NEB-300NWA-ANH	95.2 %	25 A	13.2 mm	0.52 in	58.4 mm	0.89 in	2.3 in	22.7 mm	Intermediate Bus Converter	OCP OTP OVP Remote On/Off UVLO	125 °C	-40 C	Through Hole	1	Active Low Enable	40 V	ITE (Commercial)	2250 VDC	300 W	5-DIP Module 1/8 Brick	12 V	60 V
CUI Inc. NEB-300NWA-AN	95.2 %	25 A	10.2 mm	0.4 "	58.4 mm	0.89 in	2.3 in	22.7 mm	Intermediate Bus Converter	OCP OTP OVP Remote On/Off UVLO	125 °C	-40 C	Through Hole	1	Active Low Enable	40 V	ITE (Commercial)	2250 VDC	300 W	5-DIP Module 1/8 Brick	12 V	60 V
CUI Inc. NEB-300DWA-ANH	95.2 %	25 A	13.2 mm	0.52 in	58.4 mm	0.89 in	2.3 in	22.7 mm	Intermediate Bus Converter Digital	OCP OTP OVP Remote On/Off UVLO	125 °C	-40 C	Through Hole	1	Active Low Enable	40 V	ITE (Commercial)	2250 VDC	300 W	15-DIP Module 1/8 Brick	12 V	60 V
