G51MH7-P Series
Manufacturer: ODU
Beta
⌘K
ODU MEDI-SNAP RECEPT, STY 5, SZ
| Part | Orientation | Contact Material | Color | Shell Size - Insert | Shielding | Fastening Type | Number of Positions | Voltage Rating | Primary Material | Ingress Protection | Mounting Feature | Current Rating (Amps) | Contact Finish - Mating | Mounting Type | Shell Material | Insert Material | Termination | Connector Type | Operating Temperature [Max] | Operating Temperature [Min] | Applications | Material Flammability Rating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
H | Brass | Gray | 1 | Unshielded | Detent Lock Push-Pull | 5 | 35 V | Plastic | IP50 - Dust Protected | Bulkhead - Front or Rear Side Nut | 7.5 A | Gold | Panel Mount Through Hole | Polysulfone (PSU) | Polyetheretherketone (PEEK) | Solder | Receptacle Female Sockets | 120 °C | -50 °C | Industrial Medical Testing Equipment & Measurement | UL94 V-0 | |
H | Brass | Gray | 1 | Unshielded | Detent Lock Push-Pull | 2 | 48 VDC | Plastic | IP50 - Dust Protected | Bulkhead - Front or Rear Side Nut | 12 Amps | Gold | Panel Mount Through Hole | Polysulfone (PSU) | Polyetheretherketone (PEEK) | Solder | Receptacle Female Sockets | 120 °C | -50 °C | Industrial Medical Testing Equipment & Measurement | UL94 V-0 | |
H | Brass | Gray Green | 1 | Unshielded | Detent Lock Push-Pull | 48 VDC | Plastic | IP50 - Dust Protected | Bulkhead - Front or Rear Side Nut | 12 Amps | Gold | Panel Mount Through Hole | Polysulfone (PSU) | Polyetheretherketone (PEEK) | Solder | Receptacle Female Sockets | 120 °C | -50 °C | Industrial Medical Testing Equipment & Measurement | UL94 V-0 | ||
H | Brass | Blue Gray | 1 | Unshielded | Detent Lock Push-Pull | 7 | 36 VDC | Plastic | IP50 - Dust Protected | Bulkhead - Front or Rear Side Nut | 6 A | Gold | Panel Mount | Polysulfone (PSU) | Polyetheretherketone (PEEK) | Receptacle Female Sockets | 120 °C | -50 °C | Industrial Medical Testing Equipment & Measurement | UL94 V-0 | ||
H | Brass | Blue Gray | 1 | Unshielded | Detent Lock Push-Pull | 6 | 36 VDC | Plastic | IP50 - Dust Protected | Bulkhead - Front or Rear Side Nut | 6 A | Gold | Panel Mount Through Hole | Polysulfone (PSU) | Polyetheretherketone (PEEK) | Solder | Receptacle Female Sockets | 120 °C | -50 °C | Industrial Medical Testing Equipment & Measurement | UL94 V-0 | |
H | Brass | Gray | 1 | Unshielded | Detent Lock Push-Pull | 5 | 35 V | Plastic | IP50 - Dust Protected | Bulkhead - Front or Rear Side Nut | 7.5 A | Gold | Panel Mount | Polysulfone (PSU) | Polyetheretherketone (PEEK) | Receptacle Female Sockets | 120 °C | -50 °C | Industrial Medical Testing Equipment & Measurement | UL94 V-0 | ||
H | Brass | Blue Gray | 1 | Unshielded | Detent Lock Push-Pull | 14 | 25 V | Plastic | IP50 - Dust Protected | Bulkhead - Front or Rear Side Nut | 4 A | Gold | Panel Mount | Polysulfone (PSU) | Polyetheretherketone (PEEK) | Receptacle Female Sockets | 120 °C | -50 °C | Industrial Medical Testing Equipment & Measurement | UL94 V-0 |
