PUP5C04 Series

Catalog

CABLE CAT5E 8CON 24AWG GRY 1000'

Part	Number of Conductors	Voltage	Conductor Insulation	Cable Type	Length	Length	Conductor Strand	Conductor Material	Jacket Color	Wire Gauge	Jacket (Insulation) Material	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]
Panduit Corp PUP5C04IG-U	8	80 V	Fluorinated Ethylene-Propylene (FEP) Polyolefin (PO)	Multi-Pair Cat5e	304.8 m	1000 ft	Solid	Copper Bare	Gray	24 AWG	Low Smoke Poly-Vinyl Chloride (LSPVC) Plenum	5.33 mm	0.21 in
Panduit Corp PUP5C04RD-U	8	80 V	Fluorinated Ethylene-Propylene (FEP) Polyolefin (PO)	Multi-Pair Cat5e	304.8 m	1000 ft	Solid	Copper Bare	Red	24 AWG	Low Smoke Poly-Vinyl Chloride (LSPVC) Plenum	5.33 mm	0.21 in
Panduit Corp PUP5C04VL-U	8	80 V	Fluorinated Ethylene-Propylene (FEP) Polyolefin (PO)	Multi-Pair Cat5e	304.8 m	1000 ft	Solid	Copper Bare	Violet	24 AWG	Low Smoke Poly-Vinyl Chloride (LSPVC) Plenum	5.33 mm	0.21 in
Panduit Corp PUP5C04BL-U	8	80 V	Fluorinated Ethylene-Propylene (FEP) Polyolefin (PO)	Multi-Pair Cat5e	304.8 m	1000 ft	Solid	Copper Bare	Black	24 AWG	Low Smoke Poly-Vinyl Chloride (LSPVC) Plenum	5.33 mm	0.21 in
Panduit Corp PUP5C04OR-U	8	80 V	Fluorinated Ethylene-Propylene (FEP) Polyolefin (PO)	Multi-Pair Cat5e	304.8 m	1000 ft	Solid	Copper Bare	Orange	24 AWG	Low Smoke Poly-Vinyl Chloride (LSPVC) Plenum	5.33 mm	0.21 in
Panduit Corp PUP5C04BU-F	8	80 V	Fluorinated Ethylene-Propylene (FEP)	Multi-Pair Cat5e	304.8 m	1000 ft	Solid	Copper Bare	Blue	24 AWG	Low Smoke Poly-Vinyl Chloride (LSPVC)		4.8 mm	0.189 in
Panduit Corp PUP5C04GR-U	8	80 V	Fluorinated Ethylene-Propylene (FEP) Polyolefin (PO)	Multi-Pair Cat5e	304.8 m	1000 ft	Solid	Copper Bare	Green	24 AWG	Low Smoke Poly-Vinyl Chloride (LSPVC) Plenum	5.33 mm	0.21 in
