SR732H Series

Manufacturer: KOA Speer Electronics, Inc.

Catalog

Catalog

CURRENT SENSE RESISTOR

...

Part	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Power (Watts)	Power (Watts)	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Features	Composition	Supplier Device Package	Number of Terminations [custom]	Tolerance	Resistance	Ratings	Operating Temperature [Min]	Operating Temperature [Max]	Temperature Coefficient	Package / Case
KOA Speer Electronics, Inc. SR732HTTE6R80F	0.7 mm	0.028 "	3/4W	0.75 W	5 mm	0.098 in	0.197 in	2.5 mm	Automotive AEC-Q200 Current Sense Moisture Resistant	Thick Film	2010	2	1 %	6.8 Ohms	AEC-Q200	-55 C	150 °C	100 ppm/°C	2010 (5025 Metric)
KOA Speer Electronics, Inc. SR732HTTER75G	0.7 mm	0.028 "	3/4W	0.75 W	5 mm	0.098 in	0.197 in	2.5 mm	Automotive AEC-Q200 Current Sense Moisture Resistant	Thick Film	2010	2	2 %	0.75 Ohms	AEC-Q200	-55 C	150 °C	200 ppm/°C	2010 (5025 Metric)
KOA Speer Electronics, Inc. SR732HTTE1R18F	0.7 mm	0.028 "	3/4W	0.75 W	5 mm	0.098 in	0.197 in	2.5 mm	Automotive AEC-Q200 Current Sense Moisture Resistant	Thick Film	2010	2	1 %	1.18 Ohms	AEC-Q200	-55 C	150 °C	100 ppm/°C	2010 (5025 Metric)
KOA Speer Electronics, Inc. SR732HTTE7R68F	0.7 mm	0.028 "	3/4W	0.75 W	5 mm	0.098 in	0.197 in	2.5 mm	Automotive AEC-Q200 Current Sense Moisture Resistant	Thick Film	2010	2	1 %	7.68 Ohms	AEC-Q200	-55 C	150 °C	100 ppm/°C	2010 (5025 Metric)
KOA Speer Electronics, Inc. SR732HTTE62LJ	0.7 mm	0.028 "	3/4W	0.75 W	5 mm	0.098 in	0.197 in	2.5 mm	Automotive AEC-Q200 Current Sense Moisture Resistant	Thick Film	2010	2	5 %	62 mOhms	AEC-Q200	-55 C	150 °C	500 ppm/°C	2010 (5025 Metric)
KOA Speer Electronics, Inc. SR732HTTER39G	0.7 mm	0.028 "	3/4W	0.75 W	5 mm	0.098 in	0.197 in	2.5 mm	Automotive AEC-Q200 Current Sense Moisture Resistant	Thick Film	2010	2	2 %	390 mOhms	AEC-Q200	-55 C	150 °C	200 ppm/°C	2010 (5025 Metric)
KOA Speer Electronics, Inc. SR732HTTE2R0G	0.7 mm	0.028 "	3/4W	0.75 W	5 mm	0.098 in	0.197 in	2.5 mm	Automotive AEC-Q200 Current Sense Moisture Resistant	Thick Film	2010	2	2 %	2 Ohms	AEC-Q200	-55 C	150 °C	200 ppm/°C	2010 (5025 Metric)
KOA Speer Electronics, Inc. SR732HTTE1R82F	0.7 mm	0.028 "	3/4W	0.75 W	5 mm	0.098 in	0.197 in	2.5 mm	Automotive AEC-Q200 Current Sense Moisture Resistant	Thick Film	2010	2	1 %	1.82 Ohms	AEC-Q200	-55 C	150 °C	100 ppm/°C	2010 (5025 Metric)
KOA Speer Electronics, Inc. SR732HTTER100F	0.7 mm	0.028 "	3/4W	0.75 W	5 mm	0.098 in	0.197 in	2.5 mm	Automotive AEC-Q200 Current Sense Moisture Resistant	Thick Film	2010	2	1 %	0.1 Ohms	AEC-Q200	-55 C	150 °C	100 ppm/°C	2010 (5025 Metric)
KOA Speer Electronics, Inc. SR732HTTER133F	0.7 mm	0.028 "	3/4W	0.75 W	5 mm	0.098 in	0.197 in	2.5 mm	Automotive AEC-Q200 Current Sense Moisture Resistant	Thick Film	2010	2	1 %	133 mOhms	AEC-Q200	-55 C	150 °C	100 ppm/°C	2010 (5025 Metric)
