307-046 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 46POS 0.156
| Part | Material - Insulation | Termination Rows [custom] | Read Out | Number of Rows [custom] | Number of Positions/Bay/Row | Number of Positions | Mounting Type | Pitch | Pitch | Operating Temperature [Min] | Operating Temperature [Max] | Termination | Card Type | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Color | Card Thickness [Max] | Card Thickness [Min] | Contact Type | Contact Material | Gender | Contact Finish | Features | Contact Finish Thickness | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 2 | Dual | 2 | 23 | 46 | Through Hole | 3.96 mm | 0.156 in | -40 C | 105 ░C | Solder Eyelet(s) | Non Specified - Dual Edge | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Semi Bellows | Copper Alloy | Female | Tin | |||
 EDAC Inc. | Polyester Thermoplastic | 2 | Dual | 2 | 23 | 46 | Through Hole | 3.96 mm | 0.156 in | -40 C | 105 ░C | Wire Wrap | Non Specified - Dual Edge | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Semi Bellows | Copper Alloy | Female | Tin | ||||||
 EDAC Inc. | Polyester Thermoplastic | 2 | Dual | 2 | 23 | 46 | Right Angle Through Hole | 3.96 mm | 0.156 in | -40 C | 105 ░C | Solder | Non Specified - Dual Edge | Flush Mount M3 Threaded Insert Top Opening | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Semi Bellows | Copper Alloy | Female | Tin | |||||
 EDAC Inc. | Polyester Thermoplastic | 2 | Dual | 2 | 23 | 46 | Through Hole | 3.96 mm | 0.156 in | -40 C | 105 ░C | Solder | Non Specified - Dual Edge | 4-40 Flush Mount Threaded Insert Top Opening | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Semi Bellows | Copper Alloy | Female | Gold | Card Guides | 0.25 Ám | 10 Áin | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | Dual | 2 | 23 | 46 | Board Edge Straddle Mount | 3.96 mm | 0.156 in | -40 C | 105 ░C | Solder | Non Specified - Dual Edge | 4-40 Flush Mount Threaded Insert Top Opening | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Semi Bellows | Copper Alloy | Female | Gold | Card Extender Card Guides | 0.25 Ám | 10 Áin | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | Dual | 2 | 23 | 46 | Right Angle Through Hole | 3.96 mm | 0.156 in | -40 C | 105 ░C | Solder Wire Wrap | Non Specified - Dual Edge | 4-40 Flush Mount Threaded Insert Top Opening | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Semi Bellows | Copper Alloy | Female | Gold | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | Polyester Thermoplastic | 2 | Dual | 2 | 23 | 46 | Through Hole | 3.96 mm | 0.156 in | -40 C | 105 ░C | Solder | Non Specified - Dual Edge | 4-40 Flush Mount Threaded Insert Top Opening | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Semi Bellows | Copper Alloy | Female | Tin | |||||
 EDAC Inc. | Polyester Thermoplastic | 2 | Dual | 2 | 23 | 46 | Through Hole | 3.96 mm | 0.156 in | -40 C | 105 ░C | Solder | Non Specified - Dual Edge | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 " | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Semi Bellows | Copper Alloy | Female | Tin | |||
 EDAC Inc. | Polyester Thermoplastic | 2 | Dual | 2 | 23 | 46 | Through Hole | 3.96 mm | 0.156 in | -40 C | 105 ░C | Solder | Non Specified - Dual Edge | 4-40 Flush Mount Threaded Insert Top Opening | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Semi Bellows | Copper Alloy | Female | Tin | Card Guides | ||||
 EDAC Inc. | Polyester Thermoplastic | 2 | Dual | 2 | 23 | 46 | Through Hole | 3.96 mm | 0.156 in | -40 C | 105 ░C | Solder | Non Specified - Dual Edge | 4-40 Flush Mount Threaded Insert Top Opening | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Semi Bellows | Copper Alloy | Female | Tin | Card Guides |
