SFCS152405 Series

Catalog

DC DC CONVERTER 5V 15W

Part	Type	Power (Watts)	Voltage - Output 1	Number of Outputs	Voltage - Input (Min) [Min]	Package / Case	Applications	Current - Output (Max) [Max]	Voltage - Isolation	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [y]	Voltage - Input (Max) [Max]	Efficiency	Mounting Type	Operating Temperature [Min]	Operating Temperature [Max]
Cosel USA, Inc. SFCS152405B	Isolated Module	15 W	5 V	1	18 V	20-SMD Module 17 Leads	ITE (Commercial)	3 A	1000 V	29.5 mm	39.1 mm	1.54 in	0.27 "	6.8 mm	1.16 in	36 V	90 %	Surface Mount	-40 °C	85 °C
Cosel USA, Inc. SFCS152405C	Isolated Module	15 W	5 V	1	18 V	20-DIP Module 17 Leads	ITE (Commercial)	3 A	1000 V	29.5 mm	39.1 mm	1.54 in	0.27 "	6.8 mm	1.16 in	36 V	90 %	Through Hole	-40 °C	85 °C
