105309 Series

Manufacturer: Molex

Catalog

NANO-FIT VERTICAL HEADER, THROUGH HOLE, 2.50MM PITCH, SINGLE ROW, 8 CIRCUITS, WITH KINKED PINS, 0.76ΜM GOLD (AU) PLATING, BLACK, GLOW-WIRE CAPABLE, TAPE AND REEL

Part	Material Flammability Rating	Termination	Number of Positions	Contact Material	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Applications	Mounting Type	Number of Rows	Shrouding	Contact Finish - Mating	Contact Shape	Contact Finish - Post	Operating Temperature [Min]	Operating Temperature [Max]	Voltage Rating	Insulation Color	Fastening Type	Features	Contact Type	Pitch - Mating	Pitch - Mating	Style	Current Rating (Amps)	Insulation Height [z]	Insulation Height [z]	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Contact Length - Post	Contact Length - Post [x]	Connector Type	Mated Stacking Heights	Number of Positions Loaded	Insulation Material
Molex 1053093608	UL94 V-0	Kinked Pin Solder	8	Brass	1.5 µm	59 µin	Automotive General Purpose Industrial Medical Military Telecommunications	Through Hole	1	Shrouded - 4 Wall	Gold	Square	Tin	-40 °C	105 ░C	250 VDC	Black	Latch Holder	Board Guide Pick and Place	Male Pin	2.5 mm	0.098 in	Board to Cable/Wire	Varies by Wire Gauge	0.356 in	9.05 mm	30 Áin	0.76 Ám	3.2 mm	0.126 in	Header	21.3 mm	All
Molex 1053092103		Kinked Pin Solder		Brass	1.5 µm	59 µin	Automotive General Purpose Industrial Medical Military Telecommunications	Through Hole	1	Shrouded - 4 Wall		Square	Tin	-40 °C	105 ░C	250 VDC	Natural	Latch Holder	Board Guide	Male Pin	2.5 mm	0.098 in	Board to Cable/Wire	Varies by Wire Gauge	0.356 in	9.05 mm	59 Áin	1.5 Ám	3.2 mm	0.126 in	Header	21.3 mm	All	Liquid Crystal Polymer (LCP)
Molex 1053091102		Kinked Pin Solder	2	Brass	1.5 µm	59 µin	Automotive General Purpose Industrial Medical Military Telecommunications	Through Hole	1	Shrouded - 4 Wall		Square	Tin	-40 °C	105 ░C	250 VDC	Black	Latch Holder	Board Guide	Male Pin	2.5 mm	0.098 in	Board to Cable/Wire	Varies by Wire Gauge	0.356 in	9.05 mm	59 Áin	1.5 Ám	3.2 mm	0.126 in	Header	21.3 mm	All	Liquid Crystal Polymer (LCP)
Molex 1053091206		Kinked Pin Solder	6	Brass	1.5 µm	59 µin	Automotive General Purpose Industrial Medical Military Telecommunications	Through Hole	1	Shrouded - 4 Wall	Gold	Square	Tin	-40 °C	105 ░C	250 VDC	Black	Latch Holder	Board Guide	Male Pin	2.5 mm	0.098 in	Board to Cable/Wire	Varies by Wire Gauge	0.356 in	9.05 mm	15 µin	0.38 µm	3.2 mm	0.126 in	Header	21.3 mm	All	Liquid Crystal Polymer (LCP)
Molex 1053091108		Kinked Pin Solder	8	Brass	1.5 µm	59 µin	Automotive General Purpose Industrial Medical Military Telecommunications	Through Hole	1	Shrouded - 4 Wall		Square	Tin	-40 °C	105 ░C	250 VDC	Black	Latch Holder	Board Guide	Male Pin	2.5 mm	0.098 in	Board to Cable/Wire	Varies by Wire Gauge	0.356 in	9.05 mm	59 Áin	1.5 Ám	3.2 mm	0.126 in	Header	21.3 mm	All	Liquid Crystal Polymer (LCP)
Molex 1053092302		Kinked Pin Solder	2	Brass	1.5 µm	59 µin	Automotive General Purpose Industrial Medical Military Telecommunications	Through Hole	1	Shrouded - 4 Wall	Gold	Square	Tin	-40 °C	105 ░C	250 VDC	Natural	Latch Holder	Board Guide	Male Pin	2.5 mm	0.098 in	Board to Cable/Wire	Varies by Wire Gauge	0.356 in	9.05 mm	30 Áin	0.76 Ám	3.2 mm	0.126 in	Header	21.3 mm	All	Liquid Crystal Polymer (LCP)
Molex 1053091205		Kinked Pin Solder		Brass	1.5 µm	59 µin	Automotive General Purpose Industrial Medical Military Telecommunications	Through Hole	1	Shrouded - 4 Wall	Gold	Square	Tin	-40 °C	105 ░C	250 VDC	Black	Latch Holder	Board Guide	Male Pin	2.5 mm	0.098 in	Board to Cable/Wire	Varies by Wire Gauge	0.356 in	9.05 mm	15 µin	0.38 µm	3.2 mm	0.126 in	Header	21.3 mm	All	Liquid Crystal Polymer (LCP)
Molex 1053091306		Kinked Pin Solder	6	Brass	1.5 µm	59 µin	Automotive General Purpose Industrial Medical Military Telecommunications	Through Hole	1	Shrouded - 4 Wall	Gold	Square	Tin	-40 °C	105 ░C	250 VDC	Black	Latch Holder	Board Guide	Male Pin	2.5 mm	0.098 in	Board to Cable/Wire	Varies by Wire Gauge	0.356 in	9.05 mm	30 Áin	0.76 Ám	3.2 mm	0.126 in	Header	21.3 mm	All	Liquid Crystal Polymer (LCP)
Molex 1053091303		Kinked Pin Solder		Brass	1.5 µm	59 µin	Automotive General Purpose Industrial Medical Military Telecommunications	Through Hole	1	Shrouded - 4 Wall	Gold	Square	Tin	-40 °C	105 ░C	250 VDC	Black	Latch Holder	Board Guide	Male Pin	2.5 mm	0.098 in	Board to Cable/Wire	Varies by Wire Gauge	0.356 in	9.05 mm	30 Áin	0.76 Ám	3.2 mm	0.126 in	Header	21.3 mm	All	Liquid Crystal Polymer (LCP)
Molex 1053092108		Kinked Pin Solder	8	Brass	1.5 µm	59 µin	Automotive General Purpose Industrial Medical Military Telecommunications	Through Hole	1	Shrouded - 4 Wall		Square	Tin	-40 °C	105 ░C	250 VDC	Natural	Latch Holder	Board Guide	Male Pin	2.5 mm	0.098 in	Board to Cable/Wire	Varies by Wire Gauge	0.356 in	9.05 mm	59 Áin	1.5 Ám	3.2 mm	0.126 in	Header	21.3 mm	All	Liquid Crystal Polymer (LCP)
