45S201 Series
Manufacturer: Rosenberger
Beta
⌘K
1.0/2.3 RIGHT ANGLE PLUG
| Part | Mating Cycles | Operating Temperature [Min] | Operating Temperature [Max] | Dielectric Material | Body Material | Body Finish | Center Contact Plating | Voltage Rating | Impedance | Connector Type | Number of Ports | Cable Group | Shield Termination | Connector Style | Center Contact Material | Mounting Type | Housing Color | Fastening Type | Contact Termination | Frequency - Max [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Rosenberger | 500 | -55 C | 125 °C | Polytetrafluoroethylene (PTFE) | Brass | Gold | Gold | 250 V | 50 Ohms | Plug Male Pin | 1 | RG-316 | Crimp | 1.0/2.3 | Beryllium Copper | Free Hanging (In-Line) Right Angle | Gold | Push-Pull | Crimp | 2 GHz |
 Rosenberger | 500 | -55 C | 125 °C | Polytetrafluoroethylene (PTFE) | Brass | Gold | Gold | 250 V | 50 Ohms | Plug Male Pin | 1 | Solder | 1.0/2.3 | Beryllium Copper | Right Angle Through Hole | Gold | Push-Pull | Solder | 4 GHz |
