SUW31215 Series

Catalog

DC DC CONVERTER +/-15V 3W

Part	Applications	Current - Output (Max)	Current - Output (Max)	Package / Case	Efficiency	Type	Number of Outputs	Voltage - Output 2	Voltage - Isolation	Mounting Type	Voltage - Input (Max) [Max]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [z]	Voltage - Input (Min) [Min]	Power (Watts)	Voltage - Output 1	Operating Temperature [Min]	Operating Temperature [Max]	Features
Cosel USA, Inc. SUW31215BP-G	ITE (Commercial)	100 mA	100 mA	7-SMD Module	78 %	Isolated Module	2	-15 V	500 V	Surface Mount	18 V	0.59 in	0.94 in	24 mm	6.5 mm	15.1 mm	0.26 in	9 V	3 W	15 V	-40 °C	85 °C
Cosel USA, Inc. SUW31215C	ITE (Commercial)	100 mA	100 mA	7-DIP Module	78 %	Isolated Module	2	-15 V	500 V	Through Hole	18 V	0.59 in	0.94 in	24 mm	6.5 mm	15.1 mm	0.26 in	9 V		15 V	-40 °C	85 °C	OCP Remote On/Off
Cosel USA, Inc. SUW31215B-G	ITE (Commercial)	100 mA	100 mA	7-SMD Module	78 %	Isolated Module	2	-15 V	500 V	Surface Mount	18 V	0.59 in	0.94 in	24 mm	6.5 mm	15.1 mm	0.26 in	9 V	3 W	15 V	-40 °C	85 °C
