PBC18 Series

Manufacturer: Sullins Connector Solutions

Catalog

CONN HEADER R/A 18POS 2.54MM

Part	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Shrouding	Number of Rows	Termination	Insulation Height	Insulation Height	Insulation Color	Connector Type	Insulation Material	Number of Positions	Contact Finish - Post	Contact Finish - Mating	Mounting Type	Contact Length - Mating	Contact Length - Mating	Contact Length - Post [custom]	Contact Length - Post [custom]	Current Rating (Amps)	Pitch - Mating	Pitch - Mating	Contact Type	Style	Fastening Type	Material Flammability Rating	Contact Shape	Number of Positions Loaded	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Operating Temperature [Min]	Operating Temperature [Max]	Contact Material	Contact Length - Post	Contact Length - Post	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Overall Contact Length [x]	Overall Contact Length [x]	Number of Rows [custom]	Insulation Height [z]	Insulation Height [z]	Overall Contact Length	Overall Contact Length
Sullins Connector Solutions PBC18SGBN	2.54 µm	100 µin	Unshrouded	1	Solder	3.56 mm	0.14 in	Black	Header Breakaway	Polybutylene Terephthalate (PBT)	18	Tin	Gold	Right Angle Through Hole	8.08 mm	0.318 in	5.08 mm	0.2 "	3 A	0.1 "	2.54 mm	Male Pin	Board to Board Cable	Push-Pull	UL94 V-0	Square	All	0.25 µm	10 µin	-65 ░C	125 °C	Phosphor Bronze
Sullins Connector Solutions PBC18DFAN	2.54 µm	100 µin	Unshrouded		Solder	2.54 mm	0.1 in	Black	Header Breakaway	Polybutylene Terephthalate (PBT)	36	Tin	Gold	Through Hole	8.08 mm	0.318 in			3 A	0.1 "	2.54 mm	Male Pin	Board to Board Cable	Push-Pull	UL94 V-0	Square	All	0.25 µm	10 µin	-65 ░C	125 °C	Phosphor Bronze	3.05 mm	0.12 in	0.1 in	2.54 mm	13.67 mm	0.538 in	2
Sullins Connector Solutions PBC18DAAN	2.54 µm	100 µin	Unshrouded		Solder	2.54 mm	0.1 in	Black	Header Breakaway	Polybutylene Terephthalate (PBT)	36	Tin	Gold	Through Hole	5.84 mm	0.23 in			3 A	0.1 "	2.54 mm	Male Pin	Board to Board Cable	Push-Pull	UL94 V-0	Square	All	0.25 µm	10 µin	-65 ░C	125 °C	Phosphor Bronze	3.05 mm	0.12 in	0.1 in	2.54 mm	11.43 mm	0.45 in	2
Sullins Connector Solutions PBC18SBDN	2.54 µm	100 µin	Unshrouded	1	Solder	3.56 mm	0.14 in	Black	Header Breakaway	Polybutylene Terephthalate (PBT)	18	Tin	Gold	Right Angle Through Hole	5.84 mm	0.23 in			3 A	0.1 "	2.54 mm	Male Pin	Board to Board Cable	Push-Pull	UL94 V-0	Square	All	0.25 µm	10 µin	-65 ░C	125 °C	Phosphor Bronze	10.16 mm	0.4 in
Sullins Connector Solutions PBC18DGAN	2.54 µm	100 µin	Unshrouded		Solder			Black	Header Breakaway	Polybutylene Terephthalate (PBT)	36	Tin	Gold	Right Angle Through Hole	8.08 mm	0.318 in			3 A	0.1 "	2.54 mm	Male Pin	Board to Board Cable	Push-Pull	UL94 V-0	Square	All	0.25 µm	10 µin	-65 ░C	125 °C	Phosphor Bronze	2.54 mm	0.1 in	0.1 in	2.54 mm			2	6.1 mm	0.24 in
Sullins Connector Solutions PBC18SBCN	2.54 µm	100 µin	Unshrouded	1	Solder	3.56 mm	0.14 in	Black	Header Breakaway	Polybutylene Terephthalate (PBT)	18	Tin	Gold	Right Angle Through Hole	5.84 mm	0.23 in			3 A	0.1 "	2.54 mm	Male Pin	Board to Board Cable	Push-Pull	UL94 V-0	Square	All	0.25 µm	10 µin	-65 ░C	125 °C	Phosphor Bronze	7.62 mm	0.3 in
Sullins Connector Solutions PBC18DABN	2.54 µm	100 µin	Unshrouded		Solder	2.54 mm	0.1 in	Black	Header Breakaway	Polybutylene Terephthalate (PBT)	36	Tin	Gold	Through Hole	5.84 mm	0.23 in			3 A	0.1 "	2.54 mm	Male Pin	Board to Board Cable	Push-Pull	UL94 V-0	Square	All	0.25 µm	10 µin	-65 ░C	125 °C	Phosphor Bronze	5.84 mm	0.23 "	0.1 in	2.54 mm			2			0.56 in	14.22 mm
Sullins Connector Solutions PBC18SAEN	2.54 µm	100 µin	Unshrouded	1	Solder	2.54 mm	0.1 in	Black	Header Breakaway	Polybutylene Terephthalate (PBT)	18	Tin	Gold	Through Hole	5.84 mm	0.23 in			3 A	0.1 "	2.54 mm	Male Pin	Board to Board Cable	Push-Pull	UL94 V-0	Square	All	0.25 µm	10 µin	-65 ░C	125 °C	Phosphor Bronze	13.21 mm	0.52 in								0.85 in	21.59 mm
Sullins Connector Solutions PBC18DBAN	2.54 µm	100 µin	Unshrouded		Solder			Black	Header Breakaway	Polybutylene Terephthalate (PBT)	36	Tin	Gold	Right Angle Through Hole	5.84 mm	0.23 in			3 A	0.1 "	2.54 mm	Male Pin	Board to Board Cable	Push-Pull	UL94 V-0	Square	All	0.25 µm	10 µin	-65 ░C	125 °C	Phosphor Bronze	2.54 mm	0.1 in	0.1 in	2.54 mm			2	6.1 mm	0.24 in
Sullins Connector Solutions PBC18SFDN	2.54 µm	100 µin	Unshrouded	1	Solder	2.54 mm	0.1 in	Black	Header Breakaway	Polybutylene Terephthalate (PBT)	18	Tin	Gold	Through Hole	8.08 mm	0.318 in			3 A	0.1 "	2.54 mm	Male Pin	Board to Board Cable	Push-Pull	UL94 V-0	Square	All	0.25 µm	10 µin	-65 ░C	125 °C	Phosphor Bronze	10.67 mm	0.42 in								0.838 in	21.29 mm
